RSI Divergence Entry Engine [trade_w_samet]🎯 RSI Divergence Entry Engine
RSI Divergence Entry Engine is a pivot-confirmed RSI divergence, optional trend-filtering, ATR-based trade-mapping, historical visualization, alert, and statistics indicator designed to help traders study how regular bullish and bearish RSI divergences can be converted into a structured chart workflow.
The script is built around one central idea:
A confirmed RSI divergence should be treated as analytical context first, and as a tracked trade setup only when the active direction filter and trade-state rules allow it.
The engine identifies regular RSI divergence between confirmed RSI pivots and corresponding price pivots.
When a divergence is confirmed, the script can:
• Display the divergence inside the RSI panel
• Fill the region between the RSI path and its divergence reference line
• Draw a three-layer neon divergence line directly between the corresponding price pivots on the main chart
• Evaluate the active trend-filter mode
• Open one tracked bullish or bearish setup when the signal is eligible
• Calculate an ATR-based Stop Loss
• Calculate TP1, TP2, and TP3
• Extend risk/reward boxes while the trade remains active
• Preserve completed trade boxes and historical TP price labels
• Track TP3 wins, Stop Losses, Win Rate, NET R, Average R, and Profit Factor
• Display a full desktop dashboard or a compact mobile dashboard
• Send separate TradingView alert conditions
• Support one combined “Any alert() function call” workflow
• Apply Dark Mode, Light Mode, or Mobile Theme styling
The indicator includes:
• Fixed RSI 14 calculation using closing prices
• Pivot-based regular bullish divergence detection
• Pivot-based regular bearish divergence detection
• Adjustable Pivot Lookback
• Adjustable Confirmation Bars
• A fixed internal pivot-distance window
• Confirmed-bar divergence acceptance
• RSI-panel bullish and bearish divergence lines
• RSI-panel divergence-area fills
• Main-chart three-layer neon divergence lines
• Adjustable main-chart BULLISH / SELL label size
• Fixed compact RSI-panel labels
• Dark Mode
• Light Mode
• Mobile Theme
• EMA 200 Trend Filter
• Supertrend filter using ATR 10 and factor 3.0
• Higher-timeframe EMA 200 Trend Filter
• Adjustable higher timeframe
• ATR-based Stop Loss
• Adjustable ATR period
• Adjustable ATR Stop Loss multiplier
• Adjustable TP3 target from 1R to 7R
• Automatically calculated TP1 and TP2
• One active tracked trade at a time
• Conservative same-candle TP3 / SL handling
• Permanent historical TP / SL boxes
• Historical TP1, TP2, and TP3 price labels
• Dynamic active-trade price labels
• TP3 TARGET HIT labels
• Stop Loss result labels
• Full desktop statistics dashboard
• Two-row Mobile Theme dashboard
• Static alertcondition() support
• Dynamic alert() support
• “Any alert() function call” compatibility
• Bold-italic visual text
• Pure-white Dark Mode label text
• Hidden status-line input values
• Main-chart overlay visuals from a separate RSI pane
• Loaded-history trade statistics
The purpose of the script is to provide a transparent visual framework for reviewing confirmed RSI divergence, directional context, mapped risk, target structure, and bar-based historical outcomes.
It is not financial advice.
It is not an automated trading system.
It does not execute broker orders.
It does not calculate position size.
It does not guarantee that a divergence will produce a reversal.
It does not guarantee that the displayed Win Rate, NET R, or Profit Factor will continue in future market conditions.
It does not include spread, commission, slippage, latency, financing, or partial fills.
It does not reproduce the exact intrabar path inside historical candles.
━━━━━━━━━━━━━━━━━━━━━━
📌 OVERVIEW
━━━━━━━━━━━━━━━━━━━━━━
At a high level, RSI Divergence Entry Engine does the following:
• Calculates RSI using a fixed 14-period length and closing prices.
• Searches the RSI series for confirmed pivot lows and pivot highs.
• Compares each confirmed RSI pivot with the previous eligible pivot of the same type.
• Compares the corresponding price low or high with the prior price pivot.
• Identifies regular bullish divergence when RSI forms a higher low while price forms a lower low.
• Identifies regular bearish divergence when RSI forms a lower high while price forms a higher high.
• Requires the distance between the two confirmed pivots to remain inside the fixed internal range window.
• Waits for the required right-side confirmation bars before accepting a pivot.
• Displays confirmed divergence inside the RSI panel.
• Draws the same confirmed price-pivot relationship on the main chart with a neon line.
• Evaluates the selected trend-filter mode.
• Rejects a tracked entry when the trend filter does not allow that direction.
• Rejects a tracked entry when an opposite divergence is simultaneously present.
• Rejects a tracked entry while another trade is active.
• Opens a tracked trade at the close of the divergence-confirmation candle.
• Calculates Stop Loss distance from ATR.
• Places TP1 and TP2 at proportional distances inside the final TP3 target.
• Tracks only TP3 as the winning exit.
• Tracks Stop Loss as a -1R loss.
• Extends the active profit and loss boxes until the trade closes.
• Preserves completed boxes as historical trade visuals.
• Preserves historical TP1, TP2, and TP3 price labels.
• Updates the dashboard with bar-based historical statistics.
• Provides separate static alerts and combined dynamic alerts.
The script does not use machine-learning prediction.
It does not claim that RSI divergence predicts the future with certainty.
Its dashboard is not TradingView Strategy Tester.
Its statistics are calculated internally from the script’s own bar-touch rules.
━━━━━━━━━━━━━━━━━━━━━━
🧠 CORE IDEA
━━━━━━━━━━━━━━━━━━━━━━
RSI divergence describes disagreement between price direction and RSI pivot direction.
A regular bullish divergence occurs when:
• price forms a lower low
• RSI forms a higher low
A regular bearish divergence occurs when:
• price forms a higher high
• RSI forms a lower high
The divergence can indicate that momentum is not confirming the newest price extreme.
However, divergence alone does not answer:
• whether the broader trend supports the reversal
• whether price is above or below a long-term directional reference
• whether Supertrend agrees with the signal
• whether the selected higher timeframe agrees with the signal
• where a volatility-adjusted Stop Loss should be mapped
• where intermediate and final targets should be displayed
• whether another tracked trade is already active
• whether historical bar touches reached TP3 or Stop Loss first
• how the signal behaves across Dark, Light, or Mobile layouts
The script therefore combines the divergence calculation with an optional trend filter and a fixed trade-tracking model.
The complete workflow is:
RSI pivot confirmation
→ price-pivot comparison
→ regular divergence confirmation
→ RSI-panel visualization
→ main-chart neon price-divergence line
→ optional trend-filter validation
→ one-active-trade check
→ entry at confirmation-candle close
→ ATR-based Stop Loss
→ TP1 / TP2 / TP3 mapping
→ historical bar-touch tracking
→ TP3 or SL result
→ dashboard statistics
→ static and dynamic alerts
The modules are not intended to operate as unrelated indicators.
Each module supports the same process: identifying a confirmed divergence, deciding whether it is eligible for tracking, mapping the trade structure, and recording the result under explicit rules.
━━━━━━━━━━━━━━━━━━━━━━
🧩 WHY THIS SCRIPT IS NOT A SIMPLE RSI DIVERGENCE MARKER
━━━━━━━━━━━━━━━━━━━━━━
A basic RSI divergence script can stop after drawing a line between two oscillator pivots.
RSI Divergence Entry Engine continues beyond that step.
A confirmed divergence can move through the following stages:
RSI pivot appears
→ right-side confirmation bars complete
→ previous eligible RSI pivot is located
→ pivot distance is validated
→ corresponding price pivots are compared
→ bullish or bearish divergence is confirmed
→ RSI divergence region is displayed
→ main-chart neon price-divergence line is displayed
→ active trend filter is evaluated
→ opposite-direction conflict is rejected
→ existing active-trade state is checked
→ ATR risk distance is calculated
→ entry, SL, TP1, TP2, and TP3 are stored
→ trade boxes extend through time
→ TP3 or SL is detected
→ completed trade is added to statistics
→ historical TP prices remain visible
The RSI module identifies the momentum disagreement.
The trend-filter module defines whether the tracked entry is directionally permitted.
The ATR module adapts the Stop Loss distance to current volatility.
The target module translates the chosen TP3 R multiple into three visual target levels.
The trade-state module prevents overlapping tracked positions.
The statistics module summarizes the outcomes produced by those exact rules.
The alert module communicates divergence, entry, TP3, and Stop Loss events.
This coordinated process makes the publication an entry-engine framework rather than only a divergence drawing tool.
━━━━━━━━━━━━━━━━━━━━━━
⚙️ HOW THE SCRIPT WORKS
━━━━━━━━━━━━━━━━━━━━━━
The indicator operates from a separate RSI pane while using force-overlay visuals for selected elements on the main chart.
The internal RSI configuration is:
• RSI length: 14
• Source: close
• Regular bullish divergence: enabled
• Regular bearish divergence: enabled
• Hidden bullish divergence: internally disabled
• Hidden bearish divergence: internally disabled
• Minimum pivot separation: 5 bars
• Maximum pivot separation: 60 bars
The user controls:
• Pivot Lookback
• Confirmation Bars
• Main-chart signal-label size
• ATR Period
• Stop Loss Distance in ATR
• TP3 Target in R
• Trend Filter
• Higher-Timeframe Trend Timeframe
• Theme Mode
First, the script calculates RSI:
osc = ta.rsi(close, 14)
The script then detects confirmed RSI pivots:
pivotLowValue = ta.pivotlow(osc, lbL, lbR)
pivotHighValue = ta.pivothigh(osc, lbL, lbR)
A pivot is not known on the pivot candle itself.
It becomes confirmed only after the selected Confirmation Bars have closed to its right.
The script then retrieves the previous confirmed pivot value, price value, and pivot bar.
Regular bullish divergence requires:
• current RSI pivot low above the previous RSI pivot low
• current price low below the previous price low
• valid pivot distance
• confirmed current chart bar
Regular bearish divergence requires:
• current RSI pivot high below the previous RSI pivot high
• current price high above the previous price high
• valid pivot distance
• confirmed current chart bar
The confirmed divergence is then displayed in two places:
• RSI pane
• Main price chart
The trend filter is applied only to the tracked trade entry.
This means a confirmed divergence can remain visible even when:
• the selected trend filter rejects the direction
• another trade is already active
• bullish and bearish conditions conflict on the same calculation
This separation is intentional.
The divergence visual represents analytical context.
The main-chart BULLISH or SELL trade label represents an entry that the tracking engine actually accepted.
━━━━━━━━━━━━━━━━━━━━━━
📉 RSI CALCULATION
━━━━━━━━━━━━━━━━━━━━━━
The Relative Strength Index is calculated from closing prices using a fixed length of 14.
The RSI line is displayed in blue.
The RSI pane includes:
• 70 Overbought line
• 50 Middle line
• 30 Oversold line
Dark Mode uses:
• black RSI-panel background
• red Overbought line
• white dotted Middle line
• green Oversold line
Light Mode uses:
• white RSI-panel background
• dark Middle line
• red Overbought line
• green Oversold line
The 70 and 30 lines provide visual context.
They are not mandatory divergence conditions.
A bullish divergence can be detected outside the Oversold region.
A bearish divergence can be detected outside the Overbought region.
The script does not require RSI to cross 30 or 70 before accepting a divergence.
━━━━━━━━━━━━━━━━━━━━━━
🔍 PIVOT DETECTION MODEL
━━━━━━━━━━━━━━━━━━━━━━
Pivot Lookback controls the number of candles examined on the left side of a potential RSI pivot.
The default value is 5.
Higher values generally produce larger and less frequent swing points.
Lower values generally produce smaller and more frequent swing points.
Confirmation Bars controls the number of completed candles required on the right side of the potential pivot.
The default value is 1.
A higher Confirmation Bars value provides more right-side confirmation but increases delay.
A lower value confirms earlier but can identify smaller structures.
The script also requires the previous pivot to be between 5 and 60 bars away.
These minimum and maximum distance values are fixed internally to keep the public settings panel compact.
The pivot model is symmetrical:
• pivot lows are used for bullish divergence
• pivot highs are used for bearish divergence
━━━━━━━━━━━━━━━━━━━━━━
🟢 REGULAR BULLISH DIVERGENCE
━━━━━━━━━━━━━━━━━━━━━━
A regular bullish divergence is confirmed when:
• a new RSI pivot low is confirmed
• the previous eligible RSI pivot low exists
• the current RSI pivot low is higher than the previous RSI pivot low
• the current corresponding price low is lower than the previous price low
• the pivot distance is between the fixed internal limits
• the current calculation bar is confirmed
Conceptually:
Price:
lower low
RSI:
higher low
The RSI pane displays:
• a green divergence line between the two RSI pivot values
• a translucent green fill between the real RSI path and the straight divergence reference
• a BULLISH label at the confirmed pivot location
The main chart displays:
• a three-layer green neon line between the corresponding price lows
A tracked bullish trade opens only when:
• the bullish divergence is not opposed by a bearish divergence on the same calculation
• the selected trend filter allows bullish entries
• no tracked trade is currently active
• another trade did not close on the same candle
• ATR is available and greater than zero
The tracked entry price is the close of the confirmation candle.
It is not the historical pivot-low price.
━━━━━━━━━━━━━━━━━━━━━━
🔴 REGULAR BEARISH DIVERGENCE
━━━━━━━━━━━━━━━━━━━━━━
A regular bearish divergence is confirmed when:
• a new RSI pivot high is confirmed
• the previous eligible RSI pivot high exists
• the current RSI pivot high is lower than the previous RSI pivot high
• the current corresponding price high is higher than the previous price high
• the pivot distance is between the fixed internal limits
• the current calculation bar is confirmed
Conceptually:
Price:
higher high
RSI:
lower high
The RSI pane displays:
• a red divergence line between the two RSI pivot values
• a translucent red fill between the real RSI path and the straight divergence reference
• a SELL label at the confirmed pivot location
The main chart displays:
• a three-layer red neon line between the corresponding price highs
A tracked bearish trade opens only when:
• the bearish divergence is not opposed by a bullish divergence on the same calculation
• the selected trend filter allows bearish entries
• no tracked trade is currently active
• another trade did not close on the same candle
• ATR is available and greater than zero
The tracked entry price is the close of the confirmation candle.
It is not the historical pivot-high price.
━━━━━━━━━━━━━━━━━━━━━━
⏳ PIVOT CONFIRMATION AND SIGNAL TIMING
━━━━━━━━━━━━━━━━━━━━━━
This section is important.
The script uses ta.pivotlow() and ta.pivothigh().
Pivot functions require candles to the right of the pivot before confirmation.
For example, when Confirmation Bars is 1:
• the potential pivot occurs
• one additional candle closes
• the pivot becomes confirmed
• the divergence condition can then be calculated
The RSI-panel divergence line and RSI divergence label are drawn at the original pivot-bar location after confirmation.
The main-chart neon divergence line also connects the original price-pivot bars after the divergence is confirmed.
This creates a historical visual relationship between the two pivots.
It does not mean the divergence was available in realtime on the original pivot candle.
The tracked trade entry is not placed back on the pivot.
The tracked entry occurs at the close of the later candle where the divergence confirmation becomes available.
Therefore, users must distinguish between:
Pivot Visualization
Shows where the confirmed historical pivots occurred.
Trade Entry Label
Shows the candle where the script actually accepted and opened the tracked setup.
Changing Confirmation Bars changes the confirmation delay.
Increasing Confirmation Bars can materially change signal timing and historical divergence output.
━━━━━━━━━━━━━━━━━━━━━━
✨ MAIN-CHART NEON DIVERGENCE VISUALS
━━━━━━━━━━━━━━━━━━━━━━
Confirmed RSI divergences are also displayed directly on the main price chart.
Bullish divergence:
• connects the two corresponding price lows
• uses green
• uses a three-layer neon appearance
Bearish divergence:
• connects the two corresponding price highs
• uses red
• uses a three-layer neon appearance
The neon effect is created from:
• a wide transparent outer glow
• a medium inner glow
• a bright two-pixel core line
The neon line is a historical divergence visual.
It is not an entry line.
It is not a Stop Loss.
It is not a support or resistance guarantee.
The line is created only after the RSI pivot and divergence have been confirmed.
Older line objects are removed when the configured internal object limit is exceeded.
Deleting an older visual object does not change the underlying signal calculation.
━━━━━━━━━━━━━━━━━━━━━━
🎨 RSI DIVERGENCE AREA SYSTEM
━━━━━━━━━━━━━━━━━━━━━━
Inside the RSI pane, the script creates a filled polygon between:
• the actual RSI path from the first pivot to the second pivot
• the straight divergence line connecting those pivot endpoints
Bullish divergence uses a translucent green fill.
Bearish divergence uses a translucent red fill.
The purpose is to make the momentum disagreement easier to recognize than a thin line alone.
The fill does not measure probability.
A larger visual area does not automatically mean a stronger or more profitable divergence.
The fill depends on:
• RSI movement between the pivots
• distance between the pivots
• selected Pivot Lookback
• selected Confirmation Bars
• chart symbol
• timeframe
• loaded historical data
━━━━━━━━━━━━━━━━━━━━━━
🧭 TREND FILTER SYSTEM
━━━━━━━━━━━━━━━━━━━━━━
The trend filter determines whether a confirmed divergence is eligible to open a tracked trade.
Available modes are:
• Off
• EMA Trend
• Supertrend
• HTF Trend
The filter does not hide the confirmed divergence visuals.
It only changes whether the trade engine accepts the bullish or bearish entry.
This allows users to study:
• all confirmed divergence structures
• only the subset that passed the selected directional filter
The active trend reference is drawn on the main chart when a filter mode is selected.
The reference is green when the active filter state is bullish.
The reference is red when the active filter state is bearish.
━━━━━━━━━━━━━━━━━━━━━━
📈 EMA TREND FILTER
━━━━━━━━━━━━━━━━━━━━━━
EMA Trend uses a fixed chart-timeframe EMA 200.
Bullish entries are allowed when:
• chart close is above EMA 200
Bearish entries are allowed when:
• chart close is below EMA 200
When price equals the EMA exactly, neither directional condition is satisfied.
The EMA filter is intended to align bullish divergence tracking with price above a long-term average and bearish divergence tracking with price below it.
It does not guarantee that price will continue in the filtered direction.
A divergence rejected by the EMA filter can still remain visible as a divergence visual.
━━━━━━━━━━━━━━━━━━━━━━
📊 SUPERTREND FILTER
━━━━━━━━━━━━━━━━━━━━━━
Supertrend mode uses fixed internal parameters:
• ATR length: 10
• factor: 3.0
Bullish entries are allowed when the Supertrend state is bullish.
Bearish entries are allowed when the Supertrend state is bearish.
The Supertrend reference is displayed on the main chart.
The fixed parameters keep the public settings menu simple and make behavior consistent across users.
The Supertrend filter can react differently across symbols and timeframes because ATR and price structure differ.
A bullish Supertrend state does not guarantee a successful bullish divergence trade.
A bearish Supertrend state does not guarantee a successful bearish divergence trade.
━━━━━━━━━━━━━━━━━━━━━━
⏱️ HIGHER-TIMEFRAME TREND FILTER
━━━━━━━━━━━━━━━━━━━━━━
HTF Trend compares the selected higher-timeframe close with its EMA 200.
Bullish entries are allowed when:
• higher-timeframe close is above higher-timeframe EMA 200
Bearish entries are allowed when:
• higher-timeframe close is below higher-timeframe EMA 200
The default higher timeframe is 240 minutes.
The request uses:
• gaps_off
• lookahead_off
The script does not intentionally request future higher-timeframe data.
However, the currently forming higher-timeframe candle can continue changing until that higher-timeframe candle closes.
This means the realtime HTF filter state can change while the active higher-timeframe candle is still developing.
Users who require fully closed higher-timeframe confirmation should account for this timing characteristic when interpreting realtime signals.
Changing the HTF Trend Timeframe recalculates historical eligibility.
━━━━━━━━━━━━━━━━━━━━━━
🎯 ENTRY MODEL
━━━━━━━━━━━━━━━━━━━━━━
The indicator uses the close of the divergence-confirmation candle as the tracked entry reference.
A bullish trade is opened when:
• valid bullish divergence is confirmed
• no bearish divergence conflict exists
• bullish trend permission is true
• no trade is active
• no trade closed on the same candle
• ATR is valid
A bearish trade uses the mirrored conditions.
The entry is stored at close.
The script then calculates:
• ATR-based risk distance
• Stop Loss
• TP1
• TP2
• TP3
Only signals that actually open a tracked trade receive the main-chart BULLISH or SELL entry label.
A divergence visual without an entry label can therefore indicate:
• trend-filter rejection
• existing active trade
• same-candle direction conflict
• same-candle previous trade closure
• unavailable ATR
━━━━━━━━━━━━━━━━━━━━━━
🛑 ATR STOP LOSS MODEL
━━━━━━━━━━━━━━━━━━━━━━
Risk distance is calculated as:
ATR × Stop Loss Distance.
Default settings:
• ATR Period: 14
• Stop Loss Distance: 2.0 ATR
Bullish trade:
Stop Loss = entry − risk distance
Bearish trade:
Stop Loss = entry + risk distance
ATR adapts the raw price distance to current market volatility.
The script does not examine:
• market structure below the bullish signal
• market structure above the bearish signal
• spread
• instrument tick value
• account size
• position size
• broker margin
• contract specifications
The ATR Stop Loss is a visual and statistical model.
It is not a broker order.
━━━━━━━━━━━━━━━━━━━━━━
🏆 TP1 / TP2 / TP3 MODEL
━━━━━━━━━━━━━━━━━━━━━━
The user selects the final TP3 target from 1R to 7R.
The default is 2R.
TP1 and TP2 are placed automatically inside the final target distance.
TP1:
one-third of the TP3 distance
TP2:
two-thirds of the TP3 distance
For a 3R TP3 setting:
• TP1 = 1R
• TP2 = 2R
• TP3 = 3R
For a 2R TP3 setting:
• TP1 ≈ 0.67R
• TP2 ≈ 1.33R
• TP3 = 2R
TP1 and TP2 are visual guide levels.
The current statistics engine does not close partial positions at TP1 or TP2.
It does not move Stop Loss to break even after TP1 or TP2.
It does not add partial R profit when TP1 or TP2 is touched.
Only TP3 is counted as a winning trade.
A Stop Loss is counted as -1R.
━━━━━━━━━━━━━━━━━━━━━━
🚦 ONE ACTIVE TRADE AT A TIME
━━━━━━━━━━━━━━━━━━━━━━
The trade engine maintains one active tracked position.
While a trade is active:
• new bullish divergence entries are not opened
• new bearish divergence entries are not opened
• divergence visuals can still appear
• historical divergence lines can still be drawn
This prevents overlapping tracked positions from affecting the statistics model.
A new trade is also prevented from opening on the same candle that the previous trade closes.
The next eligible divergence must occur on a later candle.
This design keeps each tracked result independent under the script’s internal accounting rules.
━━━━━━━━━━━━━━━━━━━━━━
⚠️ TP3 / SL SAME-CANDLE HANDLING
━━━━━━━━━━━━━━━━━━━━━━
Historical OHLC candles do not reveal the exact sequence of every intrabar price movement.
A candle can contain both:
• the TP3 price
• the Stop Loss price
When both are touched inside the same candle, the script cannot know from OHLC data which level occurred first.
The engine uses a conservative rule:
Stop Loss receives priority.
The trade is recorded as a loss.
TP3 and Stop Loss checks begin on the candle after entry.
The entry candle cannot immediately close the tracked trade.
This avoids assuming an unknown movement sequence inside the entry candle.
The conservative priority rule can produce different outcomes from lower-timeframe or tick-based execution reconstruction.
━━━━━━━━━━━━━━━━━━━━━━
📦 TRADE BOX VISUAL SYSTEM
━━━━━━━━━━━━━━━━━━━━━━
Each tracked trade creates two main-chart boxes:
Profit Box
Extends from entry to TP3.
Stop Box
Extends from entry to Stop Loss.
Bullish and bearish trades use the same green profit-area and red risk-area color logic.
While the trade remains active, the boxes extend to the current bar.
When the trade closes, the boxes stop at the exit candle and remain visible historically.
The boxes help visualize:
• entry timing
• risk distance
• final target distance
• trade duration
• exit candle
The boxes are chart drawings.
They are not broker orders.
Older boxes are deleted when the internal historical object limit is exceeded.
━━━━━━━━━━━━━━━━━━━━━━
🏷️ ACTIVE AND HISTORICAL PRICE LABELS
━━━━━━━━━━━━━━━━━━━━━━
During an active tracked trade, the right side of the chart displays dynamic labels for:
• ENTRY
• SL
• TP1
• TP2
• TP3
Each label includes the current stored price.
The labels move to the newest bar while the trade remains active.
On the exit candle, the final prices remain visible for that calculation.
When the trade closes, permanent historical labels are created for:
• TP1
• TP2
• TP3
These historical labels remain attached to the completed trade’s right edge.
The purpose is to preserve the target-price structure after the active dynamic labels disappear.
Historical TP labels do not indicate that TP1 or TP2 was actually touched.
They display the planned target prices for the completed tracked trade.
The final result is determined only by TP3 or Stop Loss.
━━━━━━━━━━━━━━━━━━━━━━
✅ RESULT LABELS
━━━━━━━━━━━━━━━━━━━━━━
When TP3 is reached, the script prints:
TARGET HIT
The trade is counted as a win equal to the selected TP3 R value.
When Stop Loss is reached, the script prints:
SL
The trade is counted as a -1R loss.
Result labels are displayed at the corresponding exit price.
All visible chart labels use bold-italic typography.
Dark Mode label text uses pure white.
Light Mode uses dark text where required for contrast.
━━━━━━━━━━━━━━━━━━━━━━
🎨 THEME SYSTEM
━━━━━━━━━━━━━━━━━━━━━━
The indicator includes three theme modes:
• Dark Mode
• Light Mode
• Mobile Theme
Dark Mode
Designed for dark TradingView layouts.
It uses:
• black RSI-panel background
• dark dashboard surface
• white dashboard text
• pure-white chart-label text
• red brand accents
• green bullish visuals
• red bearish visuals
Light Mode
Designed for light TradingView layouts.
It uses:
• white RSI-panel background
• white dashboard surface
• dark dashboard text
• dark chart-label text where appropriate
• red brand accents
• adjusted divergence transparency
Mobile Theme
Designed for smaller screens.
It uses:
• compact main-chart labels
• smaller RSI labels
• tiny price labels
• a two-row dashboard
• Win Rate
• NET R
Mobile Theme does not display the full desktop statistics table.
Theme selection changes presentation.
It does not change the underlying divergence, trend-filter, or trade calculations.
━━━━━━━━━━━━━━━━━━━━━━
📟 DASHBOARD
━━━━━━━━━━━━━━━━━━━━━━
Dark Mode and Light Mode display the full bottom-right dashboard.
The header displays:
• RSI DIVERGENCE
• selected TP3 R value
• active Trend Filter
The full dashboard includes:
Status
Possible values:
• NO ACTIVE TRADE
• ACTIVE BUY
• ACTIVE SELL
Closed Trades
Number of completed tracked trades.
TP3 Wins
Number of trades that reached TP3 before Stop Loss under the script’s bar-touch rules.
Losses
Number of trades recorded at Stop Loss.
Win Rate
TP3 Wins divided by Closed Trades.
NET R
Gross Profit R minus Gross Loss R.
Gross Profit
Sum of winning TP3 R values.
Gross Loss
Number of losing trades expressed as R because every Stop Loss equals -1R.
Average / Trade
NET R divided by Closed Trades.
Profit Factor
Gross Profit R divided by Gross Loss R.
Mobile Theme displays only:
• Win Rate
• NET R
The dashboard is placed on the main chart even though the indicator calculates in a separate RSI pane.
━━━━━━━━━━━━━━━━━━━━━━
📊 STATISTICS METHODOLOGY
━━━━━━━━━━━━━━━━━━━━━━
The statistics are produced by the script’s internal bar-based trade tracker.
They are not imported from a broker.
They are not verified account results.
They are not TradingView Strategy Tester results.
Win Rate:
wins / closed trades
Gross Profit R:
wins × selected TP3 R
Gross Loss R:
losses × 1R
NET R:
Gross Profit R − Gross Loss R
Average R:
NET R / closed trades
Profit Factor:
Gross Profit R / Gross Loss R
When there are profitable trades but no recorded losses, the script displays 999 as a finite placeholder instead of mathematical infinity.
The statistics do not include:
• TP1 partial profits
• TP2 partial profits
• break-even exits
• trailing stops
• spread
• commission
• slippage
• swap
• latency
• order rejection
• partial fills
• position sizing
• account equity
• compounding
• taxes
Statistics depend on:
• loaded chart history
• selected symbol
• timeframe
• data provider
• Pivot Lookback
• Confirmation Bars
• Trend Filter
• HTF Trend Timeframe
• ATR Period
• Stop Loss multiplier
• TP3 target
• historical-data revisions
Changing any of these inputs can change historical results.
━━━━━━━━━━━━━━━━━━━━━━
🚨 ALERT SYSTEM
━━━━━━━━━━━━━━━━━━━━━━
The script includes static TradingView alert conditions for:
• Regular Bullish Divergence
• Hidden Bullish Divergence
• Regular Bearish Divergence
• Hidden Bearish Divergence
• BUY Entry
• SELL Entry
• TP3 Hit
• Stop Loss Hit
Regular bullish and bearish divergence are enabled in the current public configuration.
Hidden bullish and hidden bearish divergence logic is internally disabled.
The hidden alert choices can therefore appear in TradingView’s alert-condition list, but no hidden divergence event is produced while the internal hidden-divergence switches remain disabled.
The script also includes dynamic alert() calls for:
• BUY entry
• SELL entry
• TP3 hit
• Stop Loss hit
Dynamic BUY and SELL messages can include:
• tradewsamet identifier
• chart ticker
• chart timeframe
• entry price
• TP1 price
• TP2 price
• TP3 price
• Stop Loss price
• final R target
• active Trend Filter
This allows one TradingView alert using:
Any alert() function call
to receive all dynamic entry and result events.
━━━━━━━━━━━━━━━━━━━━━━
🔔 HOW TO USE ALERTS
━━━━━━━━━━━━━━━━━━━━━━
For a specific static event:
1. Add RSI Divergence Entry Engine to the chart.
2. Open TradingView’s Create Alert window.
3. Select the indicator as the condition.
4. Choose the required event.
5. Select the notification method.
6. Use an appropriate frequency.
7. Test the alert before relying on it.
For one combined dynamic workflow:
1. Add the indicator to the chart.
2. Open Create Alert.
3. Select RSI Divergence Entry Engine .
4. Select Any alert() function call.
5. Configure the delivery method.
6. Test BUY, SELL, TP3, and SL message handling.
When the script, settings, symbol, or timeframe changes materially, recreate existing alerts.
A TradingView alert can continue using the script snapshot stored when the alert was created.
Alerts are monitoring tools.
They do not execute, modify, or close broker orders.
━━━━━━━━━━━━━━━━━━━━━━
🧪 HOW TO USE THE INDICATOR
━━━━━━━━━━━━━━━━━━━━━━
A practical workflow:
1. Add RSI Divergence Entry Engine to a standard candlestick chart.
2. Select Dark Mode, Light Mode, or Mobile Theme.
3. Begin with Pivot Lookback set to 5.
4. Begin with Confirmation Bars set to 1.
5. Observe the RSI-panel divergence structures.
6. Observe the matching neon price-pivot lines on the main chart.
7. Remember that the pivot visual becomes available only after right-side confirmation.
8. Distinguish the neon divergence line from the later tracked entry label.
9. Begin with Trend Filter set to Off when studying raw divergence frequency.
10. Test EMA Trend for chart-timeframe directional alignment.
11. Test Supertrend for volatility-based directional alignment.
12. Test HTF Trend for higher-timeframe EMA context.
13. Verify the selected HTF timeframe.
14. Review the main-chart trend reference.
15. Observe whether a BULLISH or SELL entry label is accepted.
16. Review ENTRY, SL, TP1, TP2, and TP3 prices.
17. Observe the profit and risk boxes.
18. Remember that TP1 and TP2 are visual only.
19. Review the final TARGET HIT or SL result.
20. Review dashboard Win Rate and NET R.
21. Compare Dark/Light full dashboard with Mobile Theme.
22. Use alerts for monitoring rather than blind execution.
23. Review broader market structure independently.
24. Review spread, liquidity, volatility, and news conditions.
25. Define personal account risk and position size.
26. Test the exact symbol, timeframe, and data feed personally used.
The indicator is designed for structured study and monitoring.
It should not be treated as an automatic decision-maker.
━━━━━━━━━━━━━━━━━━━━━━
⚙️ SETTINGS REFERENCE
━━━━━━━━━━━━━━━━━━━━━━
🎨 Theme
Theme Mode
Dark Mode
Uses the full dark visual profile.
Light Mode
Uses the full light visual profile.
Mobile Theme
Uses compact labels and a two-row dashboard.
━━━━━━━━━━━━━━━━━━━━━━
🎯 Signal Settings
Pivot Lookback
Controls the left-side pivot search width.
Default:
5
Higher values generally create larger and less frequent pivot structures.
Confirmation Bars
Controls the number of right-side completed candles required to confirm the RSI pivot.
Default:
1
Increasing the value increases confirmation delay.
Chart Signal Label Size
Controls the main-chart BULLISH and SELL entry-label size.
Available values:
• Tiny
• Small
• Normal
• Large
• Huge
Mobile Theme overrides the selected size with a compact layout.
━━━━━━━━━━━━━━━━━━━━━━
🧭 Trend Filter
Trend Filter
Available modes:
• Off
• EMA Trend
• Supertrend
• HTF Trend
Off
Allows tracked bullish and bearish entries without directional trend filtering.
EMA Trend
Uses chart close relative to EMA 200.
Supertrend
Uses ATR 10 and factor 3.0.
HTF Trend
Uses selected higher-timeframe close relative to higher-timeframe EMA 200.
HTF Trend Timeframe
Selects the higher timeframe used by HTF Trend.
Default:
240 minutes
This setting has no effect when HTF Trend is not selected.
━━━━━━━━━━━━━━━━━━━━━━
🛡️ Trade Management
ATR Period
Controls the ATR used for risk-distance calculations.
Default:
14
Stop Loss Distance (ATR)
Multiplies ATR to calculate the Stop Loss distance.
Default:
2.0
TP3 Target (R)
Selects the final target from 1R to 7R.
Default:
2R
TP1 and TP2 are calculated automatically from the TP3 distance.
All public input values are hidden from TradingView’s status line to reduce chart-header clutter.
━━━━━━━━━━━━━━━━━━━━━━
🧠 WHAT MAKES THIS SCRIPT ORIGINAL
━━━━━━━━━━━━━━━━━━━━━━
RSI, divergence, EMA, Supertrend, ATR, risk/reward targets, and trade statistics are established technical-analysis concepts.
These concepts are not unique by themselves.
The originality of RSI Divergence Entry Engine lies in the coordinated workflow applied to them:
fixed RSI calculation
→ confirmed oscillator pivots
→ price / RSI regular divergence comparison
→ pivot-distance validation
→ RSI-path divergence filling
→ main-chart three-layer neon pivot lines
→ optional chart or higher-timeframe trend filtering
→ one-active-trade state
→ confirmation-candle entry
→ ATR-normalized Stop Loss
→ proportional TP1 / TP2 placement
→ adjustable TP3 R target
→ conservative OHLC exit handling
→ permanent risk/reward history
→ historical target-price labels
→ theme-aware chart output
→ mobile-specific dashboard
→ internal R-based statistics
→ static and dynamic alert workflows
Distinctive implementation features include:
• separating divergence context from accepted tracked entries
• displaying the same confirmed divergence in the RSI pane and on the main chart
• filling the RSI path-to-divergence region
• using a three-layer neon price-divergence line
• preserving trade boxes after closure
• preserving TP1, TP2, and TP3 planned prices historically
• allowing multiple direction-filter models inside one entry workflow
• maintaining one tracked trade at a time
• applying conservative Stop Loss priority when TP3 and SL share a candle
• offering theme-specific dashboard behavior
• reducing the Mobile Theme dashboard to Win Rate and NET R
• supporting static conditions and combined dynamic alert() messages
• keeping public settings compact while documenting fixed internal values
The script is not a collection of unrelated indicators placed on one chart.
Every component supports the same objective: converting a confirmed RSI divergence into a transparent, filterable, volatility-mapped, historically reviewable entry framework.
━━━━━━━━━━━━━━━━━━━━━━
⚠️ IMPORTANT PRACTICAL NOTES
━━━━━━━━━━━━━━━━━━━━━━
Signal frequency depends on:
• symbol
• timeframe
• data provider
• Pivot Lookback
• Confirmation Bars
• fixed 5–60 bar pivot-distance window
• Trend Filter
• HTF Trend Timeframe
• existing active-trade state
• ATR availability
• available historical data
Higher Pivot Lookback values can reduce frequency.
Higher Confirmation Bars values increase delay.
EMA Trend can reject counter-position signals relative to EMA 200.
Supertrend can change direction after price movement.
HTF Trend can remain sensitive to the currently developing higher-timeframe candle.
Only one tracked trade can be active.
A divergence can therefore be visible without becoming a tracked trade.
TP1 and TP2 are not partial exits.
Historical TP1, TP2, and TP3 labels display planned prices, not proof that every level was touched.
Dashboard statistics use loaded chart history only.
Different brokers or exchanges can produce different:
• highs
• lows
• closes
• RSI pivots
• ATR values
• divergence signals
• trend-filter states
• TP3 / SL outcomes
• dashboard statistics
Changing the chart’s available history can change the first eligible pivot pair and all later trade-state sequencing.
━━━━━━━━━━━━━━━━━━━━━━
⚠️ LIMITATIONS AND SHORTCOMINGS
━━━━━━━━━━━━━━━━━━━━━━
This script has important limitations:
It does not guarantee profitable trades.
It does not predict future price movement.
It does not execute orders.
It does not place broker Stop Loss orders.
It does not place broker Take Profit orders.
It does not calculate position size.
It does not calculate account risk.
It does not include spread.
It does not include commission.
It does not include slippage.
It does not include latency.
It does not include swap or financing.
It does not model partial fills.
It does not model order rejection.
It does not model contract specifications.
It does not model tick-by-tick execution.
It uses historical OHLC bars.
It cannot always determine whether TP3 or SL occurred first inside one candle.
It resolves same-candle TP3 / SL ambiguity in favor of Stop Loss.
It does not record TP1 or TP2 as partial profit.
It does not move Stop Loss to break even.
It does not trail Stop Loss.
It maintains one active tracked trade.
It can ignore otherwise valid new entries while a trade is active.
It uses pivot confirmation.
Pivot visuals are not available on the original pivot candle in realtime.
RSI pivot visuals are placed at the historical pivot location after confirmation.
Main-chart neon lines are created after divergence confirmation.
The HTF filter can change while the current higher-timeframe candle remains open.
A confirmed divergence can fail.
A trend-aligned divergence can fail.
A larger divergence area does not guarantee a stronger result.
A neon divergence line is not guaranteed support or resistance.
A TARGET HIT label is not broker-verified execution.
Dashboard statistics are not audited performance.
Profit Factor displays 999 when wins exist without recorded losses.
Changing settings recalculates historical conditions.
Changing symbol, timeframe, provider, or available history can change output.
Alert delivery depends on TradingView and user configuration.
Alerts do not guarantee broker execution.
For these reasons, the indicator should be used as an educational decision-support and chart-review tool, not as a standalone automated strategy.
━━━━━━━━━━━━━━━━━━━━━━
👤 WHO THIS SCRIPT MAY BE USEFUL FOR
━━━━━━━━━━━━━━━━━━━━━━
This script may be useful for traders who:
• understand basic RSI divergence
• want regular bullish and bearish divergence visuals
• prefer pivot-confirmed structures
• want divergence displayed in both RSI and price
• want a clear neon main-chart divergence line
• want optional trend filtering
• use EMA 200
• use Supertrend
• use higher-timeframe direction
• want ATR-based risk mapping
• want adjustable R targets
• want historical risk/reward boxes
• want historical planned TP prices
• want one-active-trade statistics
• want Dark, Light, and Mobile themes
• want static alerts
• want one combined dynamic alert
• understand that chart statistics are not verified trading results
It may be less suitable for users who:
• want signals on the unconfirmed pivot candle
• want no pivot delay
• want hidden divergence enabled publicly
• want every divergence to open a trade
• want multiple overlapping tracked trades
• want partial TP accounting
• want automatic break-even management
• want trailing stops
• want tick-level backtesting
• want verified Strategy Tester results
• want broker execution
• want guaranteed reversal signals
• expect a high Win Rate to continue unchanged
• expect the HTF filter to remain fixed before the higher-timeframe candle closes
━━━━━━━━━━━━━━━━━━━━━━
🧭 BEST PRACTICE SUGGESTIONS
━━━━━━━━━━━━━━━━━━━━━━
For studying raw divergence behavior:
• use Trend Filter Off
• begin with Pivot Lookback 5
• begin with Confirmation Bars 1
• observe divergence visuals before evaluating trades
• distinguish pivot location from confirmation timing
For trend-aligned divergence:
• test EMA Trend
• test Supertrend
• compare signal frequency
• review whether the filter removes useful countertrend setups
For broader directional context:
• test HTF Trend
• use a higher timeframe meaningfully above the chart timeframe
• remember that the active HTF candle can change before closing
For trade mapping:
• begin with ATR 14
• begin with Stop Loss Distance 2.0 ATR
• begin with TP3 2R
• remember that TP1 and TP2 are visual only
• review same-candle TP3 / SL cases conservatively
For chart clarity:
• use Dark Mode on dark chart layouts
• use Light Mode on light chart layouts
• use Mobile Theme on small screens
• adjust the main-chart entry-label size
• use neon divergence lines as context, not automatic entries
Always:
• wait for divergence confirmation
• review broader price structure
• review liquidity and volatility
• review session conditions
• review news risk
• define personal account risk
• define personal position size
• test the exact symbol and timeframe
• verify alerts before relying on them
• remember that every divergence can fail
━━━━━━━━━━━━━━━━━━━━━━
🔓 PUBLICATION NOTE
━━━━━━━━━━━━━━━━━━━━━━
RSI Divergence Entry Engine is published as an educational RSI-divergence, directional-filtering, ATR trade-mapping, historical-visualization, and alert tool.
The purpose of this description is to explain:
• how RSI is calculated
• how RSI pivot lows and highs are confirmed
• how Pivot Lookback affects structure selection
• how Confirmation Bars affect delay
• how the fixed pivot-distance window works
• how regular bullish divergence is identified
• how regular bearish divergence is identified
• how divergence is displayed inside the RSI pane
• how the RSI divergence area is filled
• how corresponding price pivots are displayed with neon lines
• when the pivot visuals become available
• why pivot visuals appear at historical pivot locations
• why tracked entries are placed on confirmation-candle close
• how the trend filter affects entries without hiding divergence context
• how EMA Trend works
• how Supertrend works
• how HTF Trend works
• how currently forming higher-timeframe candles affect realtime context
• how ATR risk distance is calculated
• how Stop Loss is placed
• how TP1, TP2, and TP3 are calculated
• why TP1 and TP2 are visual only
• why only TP3 counts as a win
• how one-active-trade handling works
• how same-candle TP3 / SL ambiguity is resolved
• how historical trade boxes are retained
• what historical TP labels represent
• how Dark Mode, Light Mode, and Mobile Theme differ
• what the dashboard displays
• how Win Rate, NET R, Average R, and Profit Factor are calculated
• why the statistics are not broker-verified
• what static alert conditions are available
• how “Any alert() function call” works
• what the script does not simulate
• why the combined modules form one coordinated workflow
The script is designed to support structured review.
It does not promise profitable results.
It does not remove market risk.
It does not replace independent analysis.
It does not replace personal risk management.
━━━━━━━━━━━━━━━━━━━━━━
🕒 REPAINTING, BACKPLOTTING, AND TIMING DISCLOSURE
━━━━━━━━━━━━━━━━━━━━━━
RSI Divergence Entry Engine uses pivot functions.
Pivot confirmation requires future candles relative to the original pivot location.
The number of required right-side candles is controlled by Confirmation Bars.
The script does not know that a pivot exists on the original pivot candle.
After the right-side candles close:
• the pivot becomes confirmed
• the divergence can be calculated
• the RSI divergence line is displayed at the historical pivot locations
• the RSI divergence label is displayed at the confirmed pivot location
• the main-chart neon line connects the corresponding historical price pivots
This historical placement is a visual back-reference to the confirmed pivot structure.
It must not be interpreted as a realtime signal that was available on the original pivot candle.
The tracked trade entry is not backdated.
The tracked trade opens at the close of the later confirmation candle when all entry rules are valid.
The main-chart BULLISH or SELL entry label appears on that confirmation candle.
Trade outcome checks begin on the following candle.
The HTF Trend request uses lookahead_off.
It does not intentionally access future higher-timeframe values.
However, the current higher-timeframe candle can continue developing in realtime until it closes.
Historical results can change when:
• Pivot Lookback changes
• Confirmation Bars changes
• Trend Filter changes
• HTF Trend Timeframe changes
• ATR settings change
• TP3 target changes
• chart symbol changes
• timeframe changes
• exchange or broker feed changes
• historical data is revised
• available chart history changes
Confirmed chart-bar calculations reduce unfinished current-chart-candle changes.
They do not remove pivot confirmation delay, historical pivot placement, HTF live-candle variation, data-feed differences, or market risk.
━━━━━━━━━━━━━━━━━━━━━━
🛡️ DISCLAIMER
━━━━━━━━━━━━━━━━━━━━━━
RSI Divergence Entry Engine is provided for educational and informational purposes only.
It does not constitute financial, investment, trading, legal, accounting, or tax advice.
No indicator can guarantee future results.
Markets are uncertain.
Momentum changes.
Volatility changes.
Trend changes.
Liquidity changes.
Historical chart behavior does not ensure future performance.
Every user is responsible for their own:
• analysis
• validation
• symbol selection
• timeframe selection
• trend-filter selection
• execution planning
• Stop Loss placement
• target planning
• position sizing
• risk management
• alert configuration
• trading decisions
• broker execution
• legal obligations
• tax obligations
The RSI pivots, divergence lines, divergence fills, neon price-pivot lines, trend references, BULLISH labels, SELL labels, ENTRY labels, Stop Loss levels, TP1 levels, TP2 levels, TP3 levels, trade boxes, historical target labels, TARGET HIT labels, SL labels, dashboard statistics, Win Rate, NET R, Average R, Profit Factor, and alerts are visual analysis tools only.
A bullish divergence is not a guaranteed reversal.
A bearish divergence is not a guaranteed reversal.
An EMA-aligned signal is not guaranteed to succeed.
A Supertrend-aligned signal is not guaranteed to succeed.
A higher-timeframe aligned signal is not guaranteed to succeed.
A TARGET HIT label is not proof of an actual broker fill.
An SL label is not proof of an actual broker fill.
The dashboard is not verified account performance.
The statistics are not audited.
The script does not include spread, commission, slippage, latency, financing, partial fills, order rejection, position sizing, account equity, or broker-specific execution behavior.
Use the script as a structured RSI-divergence review, directional-filtering, trade-mapping, and monitoring framework—not as a promise of profitability or a substitute for independent judgment.
Indicatore
Uptrick: Flow Expansion TrendIntroduction
Uptrick: Flow Expansion Trend (FET) is an overlay tool built around an efficiency-adaptive midline that speeds up or slows down based on how directional recent price movement has been. The midline is paired with a volatility-based signal boundary and a minimum flow-strength filter to determine confirmed trend flips, and the script includes a market-state read that classifies current conditions as directional, developing, or compressed. Signal labels can be anchored to price highs and lows, a fixed ATR distance from price, or the midline itself.
Originality
This script's core is an efficiency ratio, calculated as the net price movement over a lookback divided by the sum of all bar-to-bar movement over that same lookback, which produces a value between 0 and 1 describing how directional versus choppy the recent path has been. Rather than using this ratio as a standalone oscillator, it is fed into the smoothing constant of the midline itself, so the midline's responsiveness continuously adjusts between a fast and slow smoothing constant based on current market efficiency. This is what separates the midline from a standard moving average, since it does not use a fixed lookback response but instead reshapes itself with the character of the move.
The signal boundary distance around the midline is also adaptive: it widens or narrows based on the same efficiency reading, so the distance price must travel to trigger a trend flip contracts in efficient, directional conditions and expands in choppier ones. A trend flip additionally requires a minimum flow-strength threshold, a normalized measure of the midline's own rate of change relative to ATR, so a boundary breach alone is not sufficient to flip the trend without accompanying follow-through in the midline's slope.
Combining an adaptive midline, an adaptive signal boundary, and a flow-strength confirmation filter into a single confirmed-trend mechanism is the original contribution of this script, since each of the three components is derived from the same efficiency and volatility inputs but serves a distinct role in preventing premature or noise-driven flips. The selectable signal anchor further separates the trend calculation from the signal display, letting traders choose whether labels sit at the bar's high/low, a fixed ATR offset from price, or directly on the midline, without altering the underlying trend logic in any way.
Features
Efficiency-adaptive midline that adjusts its smoothing speed based on how directional recent price action has been
Adaptive signal boundary that widens in choppy conditions and narrows in directional conditions
Minimum flow-strength filter required alongside a boundary breach to confirm a trend flip
Confirmed-bar trend state calculation to avoid intrabar repainting of the trend flip
Selectable signal anchor for up and down labels: high/low, fixed ATR distance from price, or midline
Adjustable ATR distance value when the ATR distance anchor is selected
Up and down trend signal labels
Optional candle coloring based on the most recent confirmed signal
Adjustable midline width
On-chart dashboard showing trend, market efficiency percentage, flow strength, market state classification, bars since the last signal, and current signal anchor mode
Four selectable dashboard positions
Four alert conditions: up signal, down signal, any trend signal, and market becoming directional
Inputs
Trend Engine: source, trend length, signal distance multiplier, minimum signal strength threshold.
Signals: show/hide up and down signals, signal anchor mode, signal ATR distance.
Visuals: candle coloring toggle, midline width, show/hide dashboard, dashboard position.
How It Works / How to Use
The script measures how efficiently price has moved over the trend length by comparing net displacement to total path length traveled. This efficiency value continuously reshapes the midline's smoothing speed, so the midline hugs price more closely in strong directional runs and lags more in choppy conditions. An ATR-based boundary is placed around the midline, with its distance also scaled by the same efficiency reading. A trend flip is confirmed only when price closes beyond this boundary on a confirmed bar and the midline's own rate of change exceeds the minimum flow-strength threshold in that direction.
Once a flip is confirmed, the up or down label is placed according to the chosen signal anchor: at the bar's high or low, at a fixed ATR distance beyond price, or directly on the midline. This is purely a display choice and does not affect when or why a trend flip occurs.
Traders can use the midline's slope and color for ongoing directional bias, the up and down signals for confirmed flips, and the dashboard's market-state classification to gauge whether current conditions are more suited to trend-following or more likely to produce choppy, range-bound behavior.
Conclusion
Uptrick: Flow Expansion Trend combines an efficiency-adaptive midline, a matching adaptive signal boundary, and a flow-strength confirmation filter into a single trend-following overlay, giving traders a trend read that reshapes itself with current market conditions rather than relying on a fixed-speed average, with flexible signal placement to suit different charting preferences.
Disclaimer
This script is provided for informational and educational purposes only and does not constitute financial advice. Past performance, whether shown historically or implied through the script's logic, does not guarantee future results. Always perform your own due diligence and risk management before making trading decisions. Indicatore
Dynamic Market Metrics [MarkitTick]💡 All-in-one market analysis suite designed to unify trend evaluation, momentum measurement, and dynamic risk management into a single, cohesive interface. Rather than relying on a scattered array of disparate indicators, this unified system synthesizes multiple dimensions of market data—including volatility, money flow, and higher-timeframe confluence—to provide a comprehensive structural overview of the current asset. It visually maps trend direction, plots actionable trade risk levels, and features a real-time heads-up display (HUD) dashboard to track critical market internals without cluttering the charting workspace.
● Overview
✨ Originality and Utility
Traditional technical analysis often forces traders to compromise between lagging trend followers and noisy momentum oscillators. This script solves that divergence by integrating an adaptive trend baseline with volume-weighted momentum constraints. It is unique in its ability to automatically map forward-looking risk-to-reward brackets the moment a structural shift is confirmed. Instead of guessing where to place stops and targets, the system calculates these thresholds dynamically based on real-time volatility, offering a strictly objective framework for trade management. This eliminates the need for messy chart mashups, replacing them with a highly organized, singular logic engine.
🔬 Methodology and Concepts
The core engine of this tool operates on an abstracted synthesis of price volatility and money flow dynamics.
The primary trend anchor is established by evaluating average true price ranges against the flow of capital entering or exiting the asset.
Rather than relying on simple price crosses, the baseline only shifts when confirmed by underlying volume and momentum pressures.
A specialized breakout override mechanism constantly monitors for abnormal momentum spikes. If a sudden surge in directional velocity exceeds the baseline volatility threshold, the system immediately recalculates the trend state to adapt to the new market structure.
Trade levels are generated using a dynamic risk parity model. The system measures the precise distance between the confirmed entry trigger and the structural invalidation point, projecting synchronized target tiers that maintain strict mathematical risk-to-reward ratios.
All higher-timeframe data integration is strictly coded using offset historical referencing, ensuring absolute data integrity and preventing any future leakage or repainting artifacts.
🎨 Visual Guide
The script utilizes a clean, professional aesthetic, heavily reliant on dynamic colors and structured dashboard elements.
• The Trend Anchor and Cloud
Trend Line: A distinct, segmented line that tracks the primary market direction. It colors dynamically based on the active state (Bullish, Bearish, or Neutral).
Dynamic Cloud: A semi-transparent filled area bridging the primary trend line and a smoothed reference baseline. The thickness of this cloud visually represents the immediate strength and momentum of the trend.
Candle Coloring: Chart candles are painted to match the active trend state, providing instant visual alignment with the underlying engine.
• Trade Levels and Signals
Signal Markers: Minimalist labels appear above or below the price action to indicate confirmed structural shifts.
Stop Loss (SL) Line: A solid line representing the exact invalidation point of the active trend.
Entry Line: A dashed line marking the exact price where the signal was confirmed.
Take Profit (TP) Lines: A series of three dashed lines representing incremental target zones.
Risk/Reward Fills: Shaded background zones visually map the risk area (Entry to SL) against the reward area (Entry to TP3), allowing for immediate visual risk assessment.
• The HUD Dashboard
Located in the top right corner, this data table provides a real-time read of market internals:
Trend State & HTF Context: Displays the current directional bias on both the local and higher timeframes.
Entry, Target, and SL: Prints the exact numerical values for the active trade parameters.
Momentum & Money Flow: Visual progress bars indicating the current intensity of price movement and capital flow.
Volatility: Indicates whether the market is currently in a state of expansion or contraction.
Trend Age: A counter showing exactly how many bars have elapsed since the current trend began.
📖 How to Use
The system is designed to be highly objective. Monitor the chart for a confirmed signal marker, which indicates a shift in the underlying structural trend. Once a signal fires, the script will automatically render the Entry, Stop Loss, and Take Profit levels.
Validation: Before considering the signal, check the HUD Dashboard. A high Momentum score and an aligned Higher Timeframe (HTF) Context significantly increase the probability of continuation.
Execution: Use the exact printed Entry line for placement. The Stop Loss line dictates the hard invalidation point where the premise of the trend is broken.
Management: As price moves in the anticipated direction, manage the position by scaling out or moving protective stops as the asset crosses the TP1, TP2, and TP3 thresholds.
Breakouts: If a sudden momentum burst triggers an override, the trend state will flip immediately. Treat these as aggressive volatility expansions that require tighter risk management.
⚙️ Inputs and Settings
The settings panel is modularized for precise user control:
• Core & Breakout
ATR Mult & Length: Adjusts the core sensitivity of the volatility engine. Lower values create a tighter, more reactive baseline.
BO Override & Sens: Toggles the momentum breakout detection and dictates how much abnormal velocity is required to override the primary trend.
• Higher Timeframe (HTF)
Show HTF & TF: Enables the integration of a secondary, longer-term timeframe to act as a directional filter.
• Trade Tools & Cloud
Show Trade Levels: Toggles the rendering of the dynamic Entry, SL, and TP lines.
Cloud Settings: Controls the length, transparency, and rendering of the visual trend cloud and candle coloring.
• Alerts & Colors
JSON Action Strings: Allows users to input custom formatted strings for Long, Short, and Close actions, perfectly integrating with automated third-party execution platforms.
Colors: Fully customizable palettes for all lines, fills, dashboards, and signal markers.
🔍 Deconstruction of the Underlying Scientific and Academic Framework
The architectural foundation of this system rests on auction market theory and the statistical properties of volatility clustering. Financial markets operate through continuous auctions where price discovery is driven by the aggressive absorption of resting liquidity. This engine abstracts that process by measuring the standard deviation of price excursions—quantifying the asset's true range—and mapping it against the directional flow of capital.
By analyzing the divergence between pure price action and volume-weighted accumulation, the system identifies the true mean of value. When price deviates beyond these statistical bounds accompanied by extreme momentum, it signals a structural paradigm shift rather than a standard mean-reversion event. Furthermore, the embedded risk parity model abandons static numerical thresholds in favor of dynamic proportional scaling. The reward brackets are continuously mathematically linked to the localized volatility of the anchor point, ensuring that the risk-to-reward distribution remains statistically constant regardless of the asset's current expansion or contraction phase.
⚠️ Disclaimer
All provided scripts and indicators are strictly for educational exploration and must not be interpreted as financial advice or a recommendation to execute trades. We expressly disclaim all liability for any financial losses or damages that may result, directly or indirectly, from the reliance on or application of these tools. Market participation carries inherent risk where past performance never guarantees future returns, leaving all investment decisions and due diligence solely at your own discretion. Indicatore
ATR Trend Rail🚦 ATR Trend Rail — a trend rail that knows when to shut up.
Most ATR / SuperTrend clones flip you into every chop-fest, then repaint the "perfect" entry after the candle closes. This one doesn't. It runs on a single idea: a trailing ATR band is only worth trading when the market regime agrees with it. 🎯
WHAT'S UNDER THE HOOD
📐 The rail — a trailing ATR band that latches trend state and rides price until volatility says the move is done. Adaptive, clean, no lag-heavy MA soup.
🧭 Regime filter (the whole point) — every flip is gated against a regime SMA. Leave it on your chart timeframe, or point it at an HTF for a top-down bias. Wrong side of regime? The signal never fires. This is the piece most trend tools skip entirely.
🚫 Non-repainting, for real — flips confirm on closed bars only, the regime pull runs lookahead-off with a realtime offset, and each leg's regime status locks the moment the flip bar closes. What you see in replay is what you'd have traded live. No hindsight magic.
🌫️ Faded legs — trends that fire against regime don't disappear, they dim. You still see the move; you just know it didn't earn a signal. Context, not censorship.
🔔 Alerts that behave — Bull, Bear, and Flip, confirmed-bar only. Set them once and trust them.
READ IT IN ONE GLANCE
🟢 Bright rail under price → confirmed uptrend, regime agrees
🔴 Bright rail over price → confirmed downtrend, regime agrees
⚪ Faded rail → the move exists, regime says wait
🔺 Triangle + Bull / Bear tag → a flip that passed the gate
Still useful after it's been on your chart a while. 🚦
— SlatinaTrades Indicatore
ARDI Williams Vix FixThis indicator is a reconstructed, faster, and visually distinct version of the popular Williams Vix Fix indicator (originally created by Chris Moody and later expanded by theehoganator ).
What does this indicator do?
By measuring market volatility, this indicator identifies periods of extreme fear (panic selling) and extreme greed (euphoric buying) to help locate potential market reversal points.
🚀 Key Features & Upgrades in the ARDI Version
1. Faster Execution & Code Optimization
Fully rewritten based on Pine Script v6. All legacy, commented-out, and experimental code has been cleaned up to ensure smoother and more efficient script performance on your chart.
2. New Interface & Full Support for "Fear & Greed" Phases
The indicator's visuals have been completely redesigned to simultaneously display both tops (greed) and bottoms (fear) with clear visual signals.
Candle overlays on the main chart have been removed to keep your price chart clean for price action analysis.
3. New ARDI Filter
Market noise, weak candles, and erratic signals are filtered out, significantly reducing false entries during sideways (ranging) markets.
4. Clean & Organized Settings Menu
Parameters are logically grouped and organized to make adjusting settings straightforward.
5. Rewritten Alert System
Alert logic has been completely rewritten and optimized for fast signal triggering, making it ideal for webhooks, trading bots, or mobile notifications.
💡 Important Note on Settings
The default settings have been specifically optimized for this version. However, if you adjust the input values to match the reference indicator settings, you will receive the exact classic signals.
Disclaimer: Past performance is not indicative of future results. Always practice proper risk management. Indicatore
Friendly Trend Friendly Trend is an adaptive trend-state indicator designed to answer two practical questions:
Is the current market structure in a confirmed bullish or bearish state?
Do the selected timeframes support the same directional bias?
The indicator simplifies trend reading without reducing the analysis to a basic moving-average crossover.
It combines directional efficiency, normalized price impulse, adaptive smoothing, volatility-sensitive boundaries, confirmation rules, and multi-timeframe context into one coordinated trend model.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
🧩 WHAT MAKES FRIENDLY TREND DIFFERENT
Friendly Trend is not a collection of unrelated indicators placed on the same chart.
Every component is part of one connected trend-state engine and has a specific role:
• Directional efficiency determines whether price is moving cleanly in one direction or following a noisy path.
• Normalized impulse measures the direction and strength of recent price movement.
• Adaptive smoothing changes the response speed of the trend basis according to current market conditions.
• The volatility model determines how far price must move before a change can qualify as meaningful.
• Slope, momentum, reversal-buffer, and consecutive-bar conditions confirm a new trend state.
• The multi-timeframe dashboard applies the same complete trend engine independently to each selected timeframe.
• The Overall result converts the individual timeframe states into a weighted directional score.
The script uses established mathematical building blocks such as exponential smoothing, True Range, and absolute price change.
Its original contribution is the way these measurements are connected into one adaptive trend-state architecture rather than used as separate signals or combined into a simple indicator mashup.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
🧭 DIRECTIONAL EFFICIENCY
The model compares:
• the net distance price has moved over the selected Length;
• the total path travelled by price during the same period.
A relatively direct move produces a higher efficiency value.
A market that repeatedly moves up and down while making little net progress produces a lower efficiency value.
This measurement helps the trend basis behave differently during:
• clean directional movement;
• noisy consolidation;
• uncertain or transitional conditions.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
⚡ NORMALIZED IMPULSE
The script separately calculates directional impulse by comparing:
• smoothed signed price changes;
• smoothed absolute price changes.
The result is normalized around zero:
• positive values indicate upward directional pressure;
• negative values indicate downward directional pressure;
• values close to zero indicate weak or balanced movement.
Impulse performs two functions inside the model:
It helps determine how quickly the adaptive basis should react.
It filters trend changes that are not supported by sufficient directional strength.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
📈 ADAPTIVE TREND BASIS
Friendly Trend calculates a faster and a slower smoothed price estimate.
It then blends them according to the current combination of:
• directional efficiency;
• absolute normalized impulse.
During clean directional movement, the faster estimate receives more influence, allowing the basis to follow price more closely.
During noisy or indecisive conditions, the slower estimate receives more influence, reducing unnecessary reactions to minor price fluctuations.
The result is a basis that adapts its response speed instead of using one fixed smoothing behavior in every market condition.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
🌊 ADAPTIVE TREND ZONE
The trend zone is not based on a fixed percentage or a single ATR value.
Its width combines:
• smoothed True Range;
• the mean absolute distance between price and the adaptive basis;
• the relationship between short-term and long-term volatility;
• the user-defined Band Multiplier.
The short-term versus long-term volatility ratio allows the zone to:
• expand when current market activity increases;
• contract when conditions become calmer;
• adjust to changing volatility regimes.
The volatility ratio is limited to prevent a single extreme movement from distorting the zone for an unnecessarily long period.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
✅ TREND CONFIRMATION
A new bullish state requires all of the following conditions:
• price closes above the upper adaptive boundary;
• the adaptive basis has a positive slope;
• normalized impulse is above the Momentum Filter;
• price clears the additional Reversal Buffer;
• the complete condition remains valid for the selected number of Confirmation Bars.
A bearish state uses the opposite conditions:
• price closes below the lower adaptive boundary;
• the adaptive basis has a negative slope;
• normalized impulse is below the negative Momentum Filter;
• price clears the Reversal Buffer;
• the condition remains valid for the required number of closed bars.
Once a trend is confirmed, the state remains active until the opposite trend passes the same confirmation process.
This persistence is intentional. The trend does not change merely because price returns inside the adaptive zone.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
🎨 HOW TO READ THE CHART
🟢 Green basis and green zone
A bullish trend state has been confirmed.
🔴 Red basis and red zone
A bearish trend state has been confirmed.
⚪ Gray basis
The script does not yet have enough confirmed information to assign a bullish or bearish state.
🏷️ Bullish and Bearish labels
A label marks the bar where a new trend state was confirmed.
Labels are not printed on every bar.
The colored zone visualizes the active trend structure. It is not a profit target, stop-loss level, support level, or resistance level.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
🕒 MULTI-TIMEFRAME DASHBOARD
The dashboard calculates the complete Friendly Trend engine independently on four configurable timeframes.
The default timeframes are:
• 15 minutes;
• 1 hour;
• 4 hours;
• 1 day.
Each row can display one of three states:
• Bullish
• Bearish
• Neutral
The dashboard does not copy the state of the chart timeframe into the other rows.
Each selected timeframe performs its own calculation using the same adaptive trend model.
Higher-timeframe rows use the state of the most recently completed higher-timeframe bar.
When a selected timeframe is lower than the chart timeframe, the script uses a previously completed lower-timeframe state. This conservative approach introduces a small delay but avoids presenting an unfinished lower-timeframe candle as a confirmed trend.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
⚖️ OVERALL TREND
The Overall result is not calculated through a simple majority vote.
Each timeframe state is converted into a numerical value:
• Bullish = +1
• Bearish = −1
• Neutral = 0
The values are then weighted according to timeframe duration.
Larger timeframes receive more influence through logarithmic weighting, while smaller timeframes continue to contribute to the result.
The normalized score is classified as:
• Bullish when it is above the Overall Threshold;
• Bearish when it is below the negative Overall Threshold;
• Mixed when it remains between the two thresholds.
This means that two short-term bullish readings do not automatically override bearish conditions on both the 4-hour and daily timeframes.
A Mixed result indicates disagreement or insufficient directional alignment. It is not a separate market direction.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
🛠️ HOW TO USE FRIENDLY TREND
Friendly Trend is designed primarily as a directional filter, not as a complete entry system.
One possible workflow is:
1. Identify the broader bias
Use Overall to understand the weighted multi-timeframe direction.
2. Review timeframe alignment
Check the individual dashboard rows to see where agreement or disagreement occurs.
3. Confirm the local trend
Use the trend state on the chart timeframe as the immediate directional context.
4. Apply an independent entry method
Combine the indicator with your own:
• market-structure setup;
• entry conditions;
• stop placement;
• position-sizing rules;
• exit plan.
5. Treat Mixed conditions cautiously
A Mixed result suggests that directional alignment is weak or divided.
Instead of forcing a bullish or bearish interpretation, traders may choose to reduce directional conviction until the timeframes become more aligned.
For example, a trader may prioritize long setups when both the chart state and Overall are Bullish, while avoiding countertrend setups when the higher timeframes remain strongly Bearish.
This is an example of interpretation, not a trading recommendation.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
⚙️ MAIN SETTINGS
Length
Controls the main observation window used by:
• the directional-efficiency calculation;
• the slower trend basis;
• the long-term volatility model.
Higher values generally produce:
• smoother behavior;
• fewer reactions to short-term changes;
• greater signal delay.
Lower values generally produce:
• faster reactions;
• greater sensitivity to local movement;
• more potential noise.
Band Multiplier
Controls the visible width of the adaptive trend zone.
Higher values:
• require a larger move before the trend can change;
• reduce sensitivity;
• may produce fewer signals.
Lower values:
• make the model more responsive;
• reduce the distance required for a trend change;
• may increase switching during sideways markets.
Confirmation Bars
Defines how many consecutive closed bars must satisfy all trend-change conditions.
A higher value provides stricter confirmation but also delays the signal.
Reversal Buffer
Adds extra distance beyond the displayed adaptive zone before a new trend can be confirmed.
Its purpose is to reduce rapid Bullish and Bearish changes when price repeatedly tests the zone during consolidation.
Momentum Filter
Defines the minimum normalized impulse required for a new trend.
Increasing this value rejects weaker directional moves.
Setting it too high may cause the indicator to miss gradual trends that develop without strong short-term momentum.
Overall Threshold
Controls how much weighted multi-timeframe agreement is required before Overall becomes Bullish or Bearish.
Higher values:
• require stronger agreement;
• produce more Mixed readings.
Lower values:
• classify directional alignment more easily;
• produce Bullish or Bearish results more frequently.
Time Frame 1–4
Define the four periods calculated in the dashboard.
The timeframes can be adjusted to match the user’s trading horizon.
A logical progression from lower to higher periods generally provides the clearest context.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
🔔 ALERTS
The script includes alert conditions for:
• confirmed bullish trend changes on the chart timeframe;
• confirmed bearish trend changes on the chart timeframe;
• any confirmed chart-timeframe trend change;
• bullish and bearish changes for each dashboard timeframe;
• changes of Overall to Bullish;
• changes of Overall to Bearish.
Chart-timeframe trend alerts are based on confirmed bar-close changes.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
⏱️ REAL-TIME AND CONFIRMED-BAR BEHAVIOR
The adaptive basis and visible zone can move while the current price bar is still open because they reflect live market data.
However:
• the chart trend state changes only after the bar is confirmed;
• Bullish and Bearish labels are generated only on confirmed chart bars;
• chart-timeframe trend alerts are based on confirmed state changes;
• higher-timeframe dashboard states use completed higher-timeframe bars;
• lower-timeframe dashboard states are intentionally delayed to avoid using an unfinished lower-timeframe candle as a confirmed signal.
Users should distinguish between:
• the live movement of the adaptive basis and zone;
• a confirmed change of trend state.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
⚠️ LIMITATIONS
Friendly Trend does not predict future prices.
Like any trend-following model, it may react with delay after a sudden reversal.
Confirmation Bars, the Reversal Buffer, and the Momentum Filter intentionally exchange some response speed for greater trend stability.
Sideways markets can still produce alternating trend states, especially when using:
• a short Length;
• a narrow trend zone;
• low confirmation requirements.
The indicator does not guarantee exact entries, exits, profits, or a specific win rate.
It should be used together with independent analysis and appropriate risk-management rules. Indicatore
PV56 XAUUSD 15M Institutional Liquidity ZonesI can create this TradingView Pine Script v6 indicator with only:
Green Buy Zones
Red Sell Zones
Zone name inside each box
Automatic mitigation/removal after invalidation
It will combine FVG, Order Block, Volume Imbalance, BPR, Mitigation Block, IDM, ITH/ITL, Breaker Block, Advanced/Reclaimed OB, Consolidation, and Institutional Zones.
No entry arrows, signals, TP, SL, dashboard, or trade setup. Indicatore
Indicatore
Regime Ribbon + CompassTraditional ADX asks you to read three tangled lines at once — +DI, −DI, and the ADX line — and combine them in your head in real time. This tool collapses all three into a single, intuitive read: direction by color, trend strength by height. No sub-pane needed — the entire regime picture lives right on your price chart.
◈ WHAT IT DOES
The Regime Ribbon recolors a smoothed baseline directly on your candles: green when the directional index confirms an uptrend with strength, red for a downtrend with strength, and muted gray during low-ADX chop. An optional faint background tint reinforces the current regime at a glance.
The Regime Compass — a floating right-edge gauge — turns the same read into a live instrument you can check at a glance:
Fill direction shows who's in control: the meter fills upward from its midline when bulls lead (+DI over −DI) and downward when bears lead (−DI over +DI).
Fill color matches the regime: green for an up-regime, red for a down-regime, dim gray during chop.
Fill height encodes conviction: the stronger the trend (higher ADX), the further the meter fills toward its pole. A weak or ranging market barely lifts off the midline; a powerful trend pushes the fill close to the edge.
Bull / Bear poles mark the top and bottom of the gauge so you always know which way is which.
A live readout on the meter prints the current state and ADX value — for example "▲ TREND 34", "▼ TREND 28", or "◈ CHOP 12" — and a light-blue dashed midline marks the neutral point.
One glance answers both questions traders normally have to compute from three separate lines: which way, and how much to trust it. The gauge floats to the right of the last candle so it never sits on top of your price action, and it can be slid further out to taste.
An on-chart dashboard ties everything together in one row along the bottom of the chart — no separate pane. Each cell is a live readout:
REGIME — the current state in plain terms: BULL ▲, BEAR ▼, or CHOP ◈, colored to match.
ADX — the raw ADX value plus a word for context: WEAK (below the trend threshold), TREND (trend confirmed), or STRONG (a powerful move).
STRENGTH — a compact bar that fills with ADX, so you can gauge trend power without reading the number.
+DI — the positive directional value (up-pressure).
−DI — the negative directional value (down-pressure).
BALANCE — the two directional values distilled into a single signed percentage. Positive means bulls lead, negative means bears lead, and the size shows how lopsided it is. This is the "collapsed" read at the heart of the tool.
TP/SL — the take-profit and stop-loss distances currently configured, with their unit (percent or ATR).
COOLDOWN — how many bars remain before a new signal is allowed, or "clear" when it's ready.
STATUS — the current position state: FLAT, LONG ●, or SHORT ●.
Together the ribbon, compass, and dashboard give you the full regime picture — direction, strength, the underlying directional balance, your trade parameters, and current state — all on the price chart, readable in a single glance.
◈ HOW TO USE
Read it in two steps — direction, then conviction:
Ribbon and compass green with the meter filling high → an uptrend with conviction. Continuation-style approaches tend to suit these conditions, and the taller the compass fill, the more decisive the move.
Red with the meter filling low → a downtrend with conviction.
Ribbon dim gray and the compass short (hugging the midline) → ADX is low; a chop/range regime where trend-following is prone to whipsaw and range tactics tend to fit better. Many traders simply stand aside here.
Watch the BALANCE cell and the compass together: when balance swings from negative to positive (or vice-versa) and the compass starts filling with height, that's the regime waking up — the shift from chop into a directional move.
Optional markers and funnel labels highlight the exact moment the regime flips into a confirmed strong trend, drawing example take-profit and stop-loss reference levels on the chart so you can see the setup framed end to end.
A practical workflow: use the ribbon for your at-a-glance bias, the compass for how much weight to give it, the BALANCE cell to spot early shifts, and the STATUS/COOLDOWN cells to keep your own entries disciplined.
◈ SETTINGS
Regime Engine — DI Length, ADX Smoothing, Trend Threshold (the ADX level separating trend from chop), Strong-Trend level.
Regime Ribbon — baseline length, background tint toggle.
Regime Compass — right-edge offset, width, height (in ATR).
Trade Levels — TP/SL in Percent or ATR, ATR length, TP/SL box toggle.
Risk Management — cooldown between signals, max bars in trade, optional EOD flatten window.
Webhook — optional alert payload with a configurable strategy ID.
Dashboard — on/off.
◈ NON-REPAINTING
All signals evaluate only on confirmed (closed) bars, and every directional value is read from closed bars — so a signal that prints will not disappear or shift intrabar. Entry logic arms on the signal bar's close and references the next bar's open, matching realistic order timing. No future data is used anywhere in the logic.
◈ DISCLAIMER
This script is a technical-analysis tool provided for educational and informational purposes only. It is not financial advice, does not predict future price movement, and does not guarantee any outcome. Trading carries a substantial risk of loss. Always do your own research and manage your own risk. The past behavior of any indicator or market condition does not indicate future results. Indicatore
Time Price Opportunity Gravity Grid [ALT_analyst]Time Price Opportunity Gravity Grid
■ Description
This script executes a strictly quantified market structure analysis by integrating Time Price Opportunity (TPO) profiling, dynamic Value Area (70%) boundaries, POC Migration matrices, and Z-Score volatility anomaly detection.
By overriding standard OHLC data limitations via lower-timeframe data injection (request.security_lower_tf), it constructs an uncompromisingly high-resolution price-density profile. Trend definitions and signal thresholds are stripped of subjective bias, executing purely on the spatial shift of accepted value and mathematical volatility expansion.
■ Core Architecture & Mechanical Edge
The algorithm mandates the simultaneous confluence of three independent mathematical variables. This relentless confluence acts as a strict mechanical filter, systematically rejecting ranging environments and isolating only mathematically significant structural shifts.
1. Value Area Calculation (70% Auction Density)
Mechanics:
Computes the absolute TPO block count per session, isolating the exact price range containing 70% of execution density (approximating 1 standard deviation).
Expansion originates strictly from the POC (maximum density node) and iteratively absorbs adjacent price rows based on relative volume weight, capturing the absolute center of the market auction.
Visualization:
Deployed as modern, semi-transparent filled boxes (Value Area Box) to eliminate visual noise, obsoleting legacy dashed-line renderings.
Application:
Price action within the Value Area is mathematically defined as balance.
A confirmed close outside this boundary signals structural imbalance. To mathematically neutralize low-volume fakeouts, breakouts are strictly invalidated unless simultaneously confirmed by both POC Migration and Volatility expansion.
2. POC Migration (Structural Trend)
Mechanics:
Evaluates the spatial shift of accepted value across consecutive sessions using a discrete step-function.
// Bullish Migration (+1):
Current_POC > Previous_POC and Current_VAL > Previous_VAL
// Bearish Migration (-1):
Current_POC < Previous_POC and Current_VAH < Previous_VAH
Application:
By demanding the simultaneous directional shift of both the peak density (POC) and the boundary floor/ceiling (VAL/VAH), the script verifies that the core market consensus has definitively relocated.
3. Volatility Z-Score (Anomaly Detection)
Mechanics & Equation:
Z_Score = (ATR(14) - SMA(ATR(14), 100)) / StDev(ATR(14), 100)
Calculation Rationale:
To measure exactly how many standard deviations the current volatility deviates from its 100-period baseline, standardizing volatility spikes across all asset classes regardless of absolute price.
Expected Output Example:
If current ATR is 1.5, 100-period mean is 1.0, and standard deviation is 0.2, the Z-Score outputs 2.5 (+2.5 standard deviations above the mean).
Application:
A Z-Score strictly > 2.0 flags a statistical outlier (top ~2.2% of historical occurrences). The algorithm enforces this threshold to ensure breakouts are driven by aggressive, statistically significant kinetic expansion, rejecting market noise.
4. Gaussian Liquidity Grid Distortion
Mechanics & Equation:
Pull_Factor = Math.exp(-(Distance_Y^2) / (2 * Pull_Radius^2))
Calculation Rationale:
Utilizes a Gaussian decay function to translate historical price congestion into a gravitational pull on the background grid, mathematically quantifying market memory.
Expected Output Example:
If price is 100 ticks away with a radius of 200, the function outputs a multiplier of ~0.882, pulling the visual grid line 88.2% closer to the price center.
Application:
Distorted grid zones visually map historical liquidity pools (high probability of deceleration/mean reversion). Smooth grids indicate liquidity vacuums for rapid price discovery.
■ Signal Execution Rules
Signals execute ONLY upon total alignment:
Long Entry: Close strictly > active POC, Structural Trend = +1, Z-Score > 2.0.
Short Entry: Close strictly < active POC, Structural Trend = -1, Z-Score > 2.0.
Risk Management: Invalidations must mathematically reside outside the active Value Area (below VAL for longs, above VAH for shorts).
Disclaimer
This script provides objective mathematical analysis for educational purposes. It does not constitute financial advice.
Indicatore
Volatility Squeeze Scanner MTF [StrixEDGE]Overview
A multi-timeframe volatility squeeze detector that identifies when Bollinger Bands contract inside Keltner Channels across four configurable timeframes simultaneously. The indicator combines squeeze state detection with a LazyBear-method momentum oscillator and a real-time consensus engine, giving traders a structured view of cross-timeframe compression without switching charts.
Volatility squeezes represent periods of contracting price action — energy building before a directional move. Detecting them on a single timeframe is common. Detecting them across multiple timeframes at once isolates the higher-probability setups where compression is structural, not noise.
How It Works
Squeeze Detection
A squeeze fires when the Bollinger Bands (SMA ± standard deviation) fully contract inside the Keltner Channel (SMA ± ATR). This means the upper Bollinger Band is below the upper Keltner Channel AND the lower Bollinger Band is above the lower Keltner Channel. When both conditions hold, volatility has compressed below its average range — the market is coiling.
Bull BIAS
Bear BIAS
Momentum Oscillator (LazyBear Method)
The momentum histogram is calculated as the linear regression of the difference between price and the average of the Donchian Channel midline and SMA. This produces a zero-centered oscillator that reveals both the direction and acceleration of momentum inside the squeeze.
The histogram uses a four-tone color scheme:
- Bright green — bullish momentum, accelerating
- Dark green — bullish momentum, decelerating
- Bright red — bearish momentum, accelerating
- Dark red — bearish momentum, decelerating
Squeeze-State Dots
Dots on the zero line change color based on the current chart timeframe's squeeze state:
- Orange dot — squeeze is active (BB inside KC)
- Teal dot — no squeeze (BB outside KC)
The transition from orange to teal marks the moment the squeeze fires — volatility is expanding and the move is underway.
Multi-Timeframe Consensus
The indicator runs the squeeze calculation independently on four user-defined timeframes via `request.security()`. A consensus table displays each timeframe's squeeze state, momentum direction, momentum acceleration, and squeeze duration in real time.
Consensus is reached when the number of timeframes simultaneously in squeeze meets or exceeds the user-defined threshold (default: 3 out of 4). The background subtly highlights when consensus is active, with a brighter flash on the bar where consensus is first reached.
How to Read It
Entry context:
Wait for the consensus row to show 3/4 or 4/4 CONSENSUS — this confirms compression is happening across the timeframe stack, not just locally. The higher the consensus count, the more significant the potential expansion.
Directional bias:
The MOM and DIR columns across timeframes reveal whether momentum is aligned. When most timeframes show BULL + ▲, the bias favors long. When most show BEAR + ▼, the bias favors short. Mixed readings suggest no clear directional edge — patience is warranted.
Timing the release:
Watch the zero-line dots on the current chart timeframe. When the dot transitions from orange (squeeze active) to teal (squeeze released), the coil is unwinding. The histogram's color and direction at that moment indicate the likely direction of the expansion.
Duration as context:
The DUR column shows how many bars each timeframe has been in squeeze. Longer durations generally correspond to larger eventual moves. A fresh squeeze (DUR = 1–3) may still be forming. An extended squeeze (DUR = 15+) is deeply compressed and more likely to produce a significant breakout.
Inputs
Bollinger Bands
- Length — lookback period for the SMA and standard deviation (default: 20)
- Multiplier — standard deviation multiplier for band width (default: 2.0)
Keltner Channel
- Length — lookback period for the SMA and ATR (default: 20)
- Multiplier — ATR multiplier for channel width (default: 1.5)
Timeframes
- Four independently configurable timeframes (default: 5m, 15m, 1H, 4H)
- Choose timeframes that create meaningful structure for your trading style
Consensus
- Minimum TF Consensus — how many timeframes must be in squeeze simultaneously to trigger consensus (2, 3, or 4; default: 3)
Momentum
- Momentum Source — price source for all calculations (Close, Open, High, Low, HL2, HLC3, OHLC4)
Alerts
5 alert conditions are available:
- Squeeze Consensus Reached — fires when the minimum TF consensus threshold is first met
- Squeeze Consensus Broken — fires when consensus drops below the threshold
- Consensus + Bullish Bias — consensus active with 3+ timeframes showing positive momentum
- Consensus + Bearish Bias — consensus active with 3+ timeframes showing negative momentum
- Full 4/4 Squeeze — all four timeframes in simultaneous squeeze
Indicatore
Indicatore
Indicatore
Regime Quadrant Map [XWiseTrade]Regime Quadrant Map
Part of the XWiseTrade Quant Suite. Follow so you don't miss the next one.
Most "regime" indicators sort the market into two boxes: trending or ranging. But that single axis hides the variable that actually decides whether a trend is tradeable — volatility. A market drifting up in dead-calm conditions and a market ripping up in violent conditions are both "trending," yet they demand opposite tactics. Collapsing them into one label is why so many trend filters fail exactly when you lean on them. This indicator separates the two questions that a one-dimensional filter fuses together, and maps the result onto four regimes instead of two.
Why volatility is measured as an ATR Z-score, not raw ATR
Raw ATR tells you nothing on its own — an ATR of 15 is enormous on one instrument and trivial on another, and huge in one era and small in the next. What matters is whether volatility is unusually high or low relative to this market's own recent behaviour. So ATR here is ranked against its own distribution over a lookback window and expressed as a Z-score: how many standard deviations above or below its own norm current volatility sits. That makes the reading self-referential and comparable across any symbol or timeframe, instead of an absolute number you'd have to re-learn for every chart.
Why trend is measured with Efficiency Ratio, not a moving-average slope
A rising moving average tells you price is higher than it was — it does not tell you how price got there. Efficiency Ratio does: it divides the net directional move by the total distance price actually travelled to make it. A value near 1 means a clean, purposeful move; near 0 means price thrashed back and forth to end up in nearly the same place. Two charts with an identical slope can have completely different efficiency, and that difference — not the slope — is what separates a trend you can ride from a trap. Slope measures result; Efficiency Ratio measures quality.
The four quadrants
Crossing the two axes gives four regimes, each with a distinct character:
GRIND (trending + low volatility) — a steady, efficient directional move; the kind you can lean into.
EXPANSION (trending + high volatility) — a violent directional move; momentum conditions, wider risk.
COIL (ranging + low volatility) — compression; energy building, often ahead of a breakout.
CHOP (ranging + high volatility) — whipsaw with no follow-through; the regime most accounts quietly bleed in.
How to use it
Watch the regime label and background tint for the current quadrant, or read the two plotted lines directly against their dashed thresholds — the ATR Z-score line for the volatility axis, the Efficiency Ratio line for the trend axis. Both thresholds and both lookbacks are adjustable, so you can set what counts as "high volatility" or "trending" for your own instrument and timeframe. An alert fires whenever the market crosses into a new quadrant, so you don't have to watch it to know the regime shifted.
What makes it different
Standard regime tools reduce the market to a single trend-versus-range line and treat volatility as an afterthought. This one builds regime from two independent axes, measures volatility as a self-referential Z-score rather than an absolute number, measures trend by path efficiency rather than slope, and resolves the market into four actionable states instead of two — because "trending" alone was never enough to decide how to trade it.
If this framework is useful, follow to get the rest of the Quant Suite as it drops — each script extends this model into entries, risk, and prop-firm workflows. More tools and write-ups: xwisetrade.com
These are descriptive regime classifications for discretionary use, not buy/sell signals. Indicatore
VSA TrailEffort-Displacement VSA Trail
Effort-Displacement VSA Trail is a scalping-oriented VSA-style indicator built around a custom effort-result signal gate.
The script uses common technical-analysis building blocks such as ATR, SMA, volume, candle body, and trailing-stop direction, but the signal logic and the way these parts are combined are original to this script.
The core idea is simple: a directional signal should not appear only because price crossed a trailing stop, and it should not appear only because volume increased.
A Buy or Sell label is printed only when three things align on the same bar:
1. ATR trailing-stop direction confirms the active side.
2. Volume expands above its own baseline.
3. Price displacement expands above its own baseline.
The displacement layer is calculated as:
body = abs(close - open)
gap = abs(open - previous close)
displacement = body + gap
This is the main design difference of the script.
Instead of measuring only candle body size, the script also includes the opening gap from the previous close.
This creates a stricter effort-result model: volume must be accompanied by real directional displacement before a signal is allowed.
The ATR trailing stop acts as the directional regime layer.
The volume condition acts as the effort layer.
The displacement condition acts as the result layer.
Only when direction, effort, and result confirm each other does the script print a Buy or Sell signal.
This is not a generic volume spike tool and it is not a plain ATR trailing-stop indicator.
It is a combined VSA-style confirmation model designed to reduce weak signals where volume increases but price movement does not meaningfully follow.
Public / common components used:
- ATR calculation with ta.atr()
- SMA baselines with ta.sma()
- ATR-style trailing-stop direction logic
Original elements:
- Body-plus-gap displacement confirmation
- Same-bar effort-result validation
- Signal gating that requires ATR direction, volume expansion, and displacement expansion together
- Stateful Buy/Sell logic that avoids repeating the same-side signal until direction changes
This script does not include copied third-party script code.
It was built as an original combination of standard Pine Script functions and custom signal logic.
Use case:
This indicator is intended for short-term chart analysis where the trader wants to see only those directional moments where trailing-stop bias, volume expansion, and displacement expansion confirm each other.
Limitations:
The script is not a complete trading system.
It does not include position sizing, take-profit rules, slippage modeling, spread handling, or full risk management.
Signals can still fail in choppy, illiquid, or news-driven market conditions.
Disclaimer:
This script is for educational and informational purposes only.
It is not financial advice, investment advice, or a recommendation to buy or sell any asset.
Trading involves risk.
Past signals do not guarantee future results.
Always use your own analysis and risk management. Indicatore
RSI Volume Compression RibbonRSI Volume Compression Ribbon
RSI Volume Compression Ribbon combines the standard Price RSI with a volume-weighted RSI momentum model and a multi-band compression ribbon.
The indicator is designed to make momentum contraction and expansion visually clear. Periods in which the ribbon narrows represent reduced momentum volatility and compression. A subsequent widening of the ribbon may indicate the beginning of a stronger directional move.
CORE COMPONENTS
1. Price RSI
The main RSI line is calculated from the selected price source.
It can be used for:
• Overbought and oversold analysis
• Momentum assessment
• Bullish and bearish divergence analysis
• Confirmation of exits from extreme zones
The color, transparency, and thickness of the main RSI line are fully adjustable.
2. Volume-Weighted RSI
The volume component is based on an EMA volume-weighted price:
Volume-Weighted Price =
EMA(Volume × Price) / EMA(Volume)
RSI is then calculated from this volume-weighted price.
Two smoothed Volume RSI lines are displayed:
• Fast Volume RSI — reacts more quickly to changes in volume-weighted momentum
• Slow Volume RSI — represents the broader direction of volume-weighted momentum
When the Fast Volume RSI crosses above the Slow Volume RSI, volume-weighted momentum is strengthening.
When the Fast Volume RSI crosses below the Slow Volume RSI, volume-weighted momentum is weakening.
3. Compression Ribbon
The compression ribbon consists of several volatility envelopes around the Fast Volume RSI.
The bands are calculated using the standard deviation of the Fast Volume RSI.
When the bands contract, the indicator identifies a momentum-compression environment.
When the bands begin to separate after compression, momentum volatility is expanding. This often occurs near the beginning of a stronger market impulse, although the ribbon itself does not determine the direction of the move.
Compression is evaluated relative to the recent average ribbon width, allowing the indicator to adapt to changing market conditions.
4. Crossover Dots
Black-outlined dots mark crossings between the Fast and Slow Volume RSI lines.
By default, the indicator emphasizes crossings that occur:
• During a ribbon compression
• Shortly after compression
• While the ribbon begins to expand
The dot center uses conventional directional colors:
• Green — Fast Volume RSI crosses above Slow Volume RSI
• Red — Fast Volume RSI crosses below Slow Volume RSI
All ordinary crossings can also be displayed through the settings.
Dot size, outline size, and center size are adjustable.
5. Classic RSI Zones
The indicator includes narrow RSI zones inspired by the original concept:
• 70–67: upper momentum zone
• 30–27: lower momentum zone
• 92–89: upper extreme zone
• 8–5: lower extreme zone
The width, colors, and transparency of these zones can be customized.
Optional broad backgrounds for the 0–30 and 70–100 regions are also available.
6. Active Extreme Fills
When the Price RSI moves below the oversold level, the area between the RSI and the oversold boundary is highlighted.
When the Price RSI moves above the overbought level, the corresponding upper area is highlighted.
The colors and transparency of both active fills are independently adjustable.
SIGNALS
The indicator provides alerts for:
• Bullish Volume RSI crossover near compression
• Bearish Volume RSI crossover near compression
• Any Volume RSI crossover near compression
• Price RSI exit from oversold
• Price RSI exit from overbought
Crossover signals are confirmed at bar close.
INTERPRETATION
Compression does not indicate direction by itself.
A compressed ribbon represents reduced momentum dispersion. Direction should be evaluated using:
• The direction of the Fast and Slow Volume RSI crossover
• Price structure
• Support and resistance
• Trend context
• Price RSI behavior
• Divergences
• Volume quality
A common sequence is:
Compression → Volume RSI crossover → Ribbon expansion → Momentum impulse
However, compression may also produce false starts or short-lived expansions, particularly in sideways or illiquid markets.
MARKET APPLICATION
The indicator can be applied to:
• Cryptocurrencies
• Stocks
• Futures
• Commodities
• Currency pairs
• Indices and CFDs with usable volume data
The Volume RSI component is most meaningful when the chart provides reliable volume information. On instruments with synthetic, incomplete, or unavailable volume, the Price RSI may be more reliable than the volume-weighted calculations.
SETTINGS
The indicator includes controls for:
• Price RSI length
• Overbought and oversold levels
• Volume RSI length
• Fast and slow smoothing
• Ribbon calculation length
• Ribbon deviation multiplier
• Compression threshold
• Compression lookback
• Post-compression crossover window
• Main RSI color, transparency, and width
• Zone colors and transparency
• Active fill colors and transparency
• Crossover dot size
• Classic narrow zones
• Broad RSI-zone backgrounds
CREDITS
Original concept and source code:
@wozdux — RSIVolume_2graf
This version was redesigned and rewritten in Pine Script v6 with:
• A cleaner visual structure
• Volume RSI compression analysis
• Multi-band compression ribbon
• Compression-filtered crossover dots
• Adjustable visual settings
• Classic RSI zones
• Confirmed crossover alerts
DISCLAIMER
This indicator is provided for informational and educational purposes only. It does not constitute financial or investment advice.
No indicator can predict market direction with certainty. Signals should be evaluated together with market structure, trend context, and appropriate risk management. Indicatore
Best Order Block Finder - Xcelerate TradeThe Best Order Block Finder - Enhanced - Developed by the Xcelerate Trade team.
Advanced Order Block Detection with Smart Visualization
This professional-grade indicator identifies institutional order blocks using sophisticated price action analysis, helping traders spot high-probability reversal and continuation zones.
🎯 Key Features:
Smart Detection Algorithm:
Identifies bullish and bearish order blocks based on volume pivots and price rejection
Configurable period analysis (2-20 bars) for different market conditions ( It can also be used on small timeframes 1m-15m)
Minimum percentage move filter to eliminate noise
Optional wick-based or body-based detection methods
Visual Excellence:
Clean, professional rectangular zones with customizable transparency
Color-coded labels with percentage move information
Compact design with adjustable block length (2-30 bars)
Dual color schemes: DARK and BRIGHT themes
Bullish blocks in GREEN, Bearish blocks in RED for instant recognition
Advanced Controls:
Maximum order blocks limit (5-50) to prevent chart clutter
Automatic cleanup of old/irrelevant blocks
Optional channel lines for latest order blocks
Information panel showing current OB levels
Real-time alerts for new order block formations
📈 How It Works:
Order blocks represent areas where large institutions have placed significant orders, creating imbalances that often lead to price reversals or strong reactions when retested.
Bullish Order Blocks: Form after bearish candles followed by strong bullish momentum
Bearish Order Blocks: Form after bullish candles followed by strong bearish momentum
🔔 Alert System:
New Bullish Order Block detected
New Bearish Order Block detected
Fully customizable alert messages
⚙️ Customization Options:
Adjustable detection sensitivity
Color scheme selection
Transparency controls
Block duration settings
Label visibility toggles
Perfect for:
Swing traders identifying key support/resistance levels
Scalpers looking for high-probability entry zones
Institutional analysis and smart money tracking
Multi-timeframe order block analysis
💡 Pro Tips:
Use on higher timeframes (30m - 4H+) for stronger institutional levels
Combine with volume analysis for confirmation
Watch for price reactions when retesting order blocks
Best used with proper risk management
Transform your trading with institutional-level order block analysis!
May 6
Release Notes
Xcelerate Trade – Order Block Finder (Enhanced)
Overview
A clean, rules-based Order Block tool that highlights bullish and bearish OB zones using a classic “OB candle + consecutive candles” confirmation model. It’s designed for traders who want simple, consistent OB marking without repaint-style guesswork.
How it works
Bullish OB: a bearish OB candle followed by N bullish candles (Relevant Periods) and an optional minimum % move filter.
Bearish OB: a bullish OB candle followed by N bearish candles (Relevant Periods) and an optional minimum % move filter.
OB zones are drawn as boxes and labeled on the chart once confirmation is met.
Key features
Order Block Zone modes
Open→Wick (default, matches the original method)
Body (open↔close)
Full Wick (high↔low)
Noise control via Min. Percent move threshold
Mitigation & invalidation options (optional)
Mitigation: Off / Touch / Close inside
Invalidation: Off / Touch beyond / Close beyond
After mitigation: Keep / Fade / Delete
Object management: configurable maximum OB boxes displayed to keep charts clean.
Alerts
Alert conditions for new Bullish OB and new Bearish OB
Optional alert conditions for mitigation events
Best practices
Use higher timeframes to mark “major” OB zones, then refine entries on lower timeframes.
Combine with structure (HH/HL/LH/LL), key levels, and session context for better confluence.
Developed by the Xcelerate Trade team. Indicatore
NeuPortal Forecast - sealed distributions not pathsDraws a forecast as a DISTRIBUTION at a stated horizon, never as a path.
What it plots, from values you enter yourself:
- median for the horizon
- core 50% zone (25th to 75th percentile of the asset's own historical moves over the same horizon)
- wide 80% band (10th to 90th percentile)
- the seal: a vertical line at the bar the forecast was fixed on, so left of it is observed and right of it was unknown
- an explicit invalidation level
- a computed daily read (ADX, DI, RSI, MACD, %B, EMA structure, ATR) taken from the chart itself, so the table cannot drift from the price it sits on
There is deliberately no diagonal anywhere. A line drawn from today's price to a future price is read as a claimed route, and a distribution at a horizon is not a route. The size of the expected move is stated as a vertical dimension bracket instead.
Two ways to feed it. Fill the inputs by hand, or paste a single line into "Today's line" in the first settings group, in the form key=value;key=value - useful if you generate forecasts programmatically and do not want to retype twenty fields daily. Pasted values win, missing ones fall back to the manual inputs.
Free, open source, no gating, no signals, no DMs.
Educational content - not financial advice. Indicatore
Indicatore
NQ Engine Health **NQ Engine Health**
NQ Engine Health is a session-aware trade-management and market-confirmation dashboard designed for NQ and MNQ.
During the New York session, it measures whether the current NQ move is supported by six major Nasdaq leaders, NQ price structure, VXN behavior and broader ES market context.
During London and Asia, the indicator switches to a futures-based engine using the active session open, session VWAP, NQ momentum, volume participation and ES confirmation.
The dashboard displays:
* Market direction and directional score
* Engine Health from 0% to 100%
* Strengthening, stable, losing-fuel or diverging conditions
* ES and VXN confirmation
* Individual Nasdaq leader direction and momentum
* Session-adjusted confidence
* Suggested trade-management posture
Management conditions include **Breathing Room, Normal Structure, Protect Profit and Defensive**.
This indicator does not generate trade entries. It is designed to complement a separate entry strategy, important price levels and structured risk management.
Alerts are included for Full Throttle, Losing Fuel, Divergence, Protect Profit and Defensive conditions.
For educational and analytical purposes only. No indicator can predict or guarantee market outcomes.
Indicatore
Indicatore
Indicatore
Market Structure - MTFOverview
This indicator maps market structure by detecting confirmed swing points, labelling them as HH, HL, LH or LL, and marking every structural break as either a Break of Structure (BOS) or a Change of Character (CHoCH). It runs on the chart timeframe by default and can optionally read structure from any higher timeframe while you work on a lower one.
How swings are detected
Swings come from ta.pivothigh / ta.pivotlow at a user-defined Pivot Strength. A pivot requires that many closed bars on each side before it is confirmed, so structure labels never move once drawn — the trade-off is that each swing appears with that many bars of delay.
How swings are classified
Most structure scripts label a swing high as HH whenever its wick exceeds the previous swing high. This script requires both conditions: the new swing's high must exceed the previous swing's high and its close must exceed the previous swing's close. A single wick poking above a prior high with a weak close is labelled LH instead. The low side mirrors this — LL requires both a lower low and a lower close. This produces fewer HH/LL tags and filters out swings driven entirely by liquidity wicks.
How breaks are classified
The script maintains a directional bias that flips only on a structural break:
BOS — price breaks the last swing high while bias is bullish, or the last swing low while bias is bearish. Continuation.
CHoCH — price breaks the last swing low while bias is bullish, or the last swing high while bias is bearish. This is the first break against the prevailing structure and marks a potential regime change.
Each swing level can only be broken once, so a level never fires repeated signals. A break draws a line from the origin swing to the break bar, with the label placed above the line for bullish events and below for bearish.
Break Confirmation setting
Close — a break requires a candle to close beyond the level. Stricter, fewer signals, drawn as a solid line.
Wick — any trade through the level counts. Earlier signals, drawn as a dashed line to flag that price never committed beyond it.
Structure Timeframe setting
Leave blank to follow the chart. Set it explicitly (e.g. 60) to keep higher-timeframe structure on screen while executing on a lower timeframe. Requests use lookahead_off, so higher-timeframe swings only appear after that bar closes.
Dashboard
Shows the active structure timeframe, current bias, the live swing high and swing low, and the CHoCH level — the price that would invalidate the current bias if broken.
Alerts
Four conditions: Bullish BOS, Bearish BOS, Bullish CHoCH, Bearish CHoCH.
Settings guidance
Lower Pivot Strength (3–4) gives more granular intraday structure; higher values (5–7+) give cleaner swings on daily and above. Higher values on higher timeframes generally produce more readable structure. Label Offset controls the vertical gap between text and lines in ATR units.
Notes and limitations
A CHoCH is an early warning, not confirmation — many traders wait for a subsequent BOS in the new direction before treating a reversal as established. Structure labels and break tests use different criteria by design: labels compare closes for classification, while the break test follows your Break Confirmation setting against the wick extreme, so a swing tagged LH can still produce a bullish BOS if price later closes above its high. In ranging conditions the bias will flip frequently. This tool describes structure; it does not generate entries or exits on its own. Indicatore
