VWAP Gravity Oscillator (VGO) (Intraday Only)

VWAP Gravity Oscillator (VGO)
The VWAP Gravity Oscillator (VGO) is an intraday analytical indicator designed to quantify price displacement from VWAP and the rate of change of that displacement.

The indicator models VWAP as a statistical equilibrium level and evaluates:
Price deviation from VWAP (Delta)
Momentum and acceleration of that deviation via MACD

This framework enables assessment of trend persistence versus mean-reversion pressure in intraday price action.

Methodology
VWAP Delta
Measures the signed distance between price and VWAP, representing directional bias relative to equilibrium.

MACD on Delta
Captures the first- and second-order dynamics of VWAP deviation, highlighting acceleration, deceleration, and potential inflection points.

Zero Line
Represents price–VWAP equilibrium. Crossings may indicate regime transitions.

Interpretation Guidelines
Positive Delta
Price is trading above VWAP with positive directional bias.

Negative Delta
Price is trading below VWAP with negative directional bias.

Increasing MACD
Expansion of VWAP deviation (trend reinforcement).

Decreasing or reversing MACD
Contraction of VWAP deviation (mean-reversion risk).

Intended Applications
Intraday trend validation
Early detection of trend exhaustion
Mean-reversion risk assessment
Filtering low-conviction or balanced market conditions

Implementation Notes
Designed exclusively for intraday timeframes
Automatically suppressed on higher-timeframe charts
Intended as a contextual analysis tool, not a standalone signal generator

Conceptual Summary
VGO evaluates whether price is diverging from, stabilising around, or reverting toward VWAP by analysing both displacement and its rate of change.

Release Note

Update: Gravity Thresholds & Clearer Signals

This update adds a user-defined Absolute Delta Threshold to filter low-quality signals near VWAP, along with dynamic upper and lower gravity bands (±threshold) for clearer context. The histogram is now split into Accelerating and Decelerating regimes, and visual entry/exit markers have been added for improved signal clarity.

Default behavior remains largely unchanged, and the indicator continues to operate on intraday charts only.

Release Note

Update: Volatility-Adaptive Gravity & Signal Strength Filter

This update introduces ATR-based dynamic gravity thresholds for VWAP Delta, allowing entry conditions to adapt to changing market volatility while enforcing a minimum distance from VWAP. In addition, a minimum MACD (signal) strength filter has been added to avoid weak or noisy momentum flips near equilibrium.

These enhancements improve signal quality by combining volatility-aware price displacement with momentum validation, without altering the core behavior of the indicator.

Release Note

Update: Smarter VWAP Reclaims & Less Chop Noise

This update improves how the indicator handles direction changes around VWAP. After price makes a meaningful move away from VWAP, the indicator now allows reversal entries on VWAP reclaim, without forcing price to stay inside the gravity range. This helps capture real regime shifts instead of missing them.

It also reduces over-trading during VWAP chop by preventing repeated entries when price keeps oscillating around VWAP. New entries are allowed only when a fresh context is formed.

In testing, this logic was found to work best on 5-minute charts, where VWAP structure and momentum signals are more stable.

Overall, this makes the indicator more reliable in range days, trend days, and transition phases, while keeping the original momentum-confirmation logic intact.

Release Note

Update: Flexible Gravity Limits & Safer Bounds Handling
This update makes gravity thresholds more flexible and robust.
Default behaviour: Both lower and upper gravity limits are now OFF by default, allowing entries without distance constraints unless explicitly configured.
Added safer bound handling to prevent invalid or collapsed gravity ranges.
Upper and lower gravity bands (and cloud) are now plotted only when they are meaningful, avoiding scale distortion and improving chart readability.
Continuation logic remains unchanged, while VWAP reclaim (regime-change) logic continues to ignore gravity limits by design.

These changes improve usability out of the box, reduce visual clutter, and make gravity constraints fully opt-in for advanced users.

Release Note

Update: Triple-Confirmation Engine + Custom Momentum EMA Length 🔥

This release brings a major upgrade to VGO’s entry logic and momentum tuning:
1. Triple-Confirmation Entry Rules (Stronger, Cleaner Signals)

A position is now entered only when all three confirmations align:
Delta > 0
– Price must be on the correct side of VWAP (context / regime)
Velocity > 0 (Fast EMA on Delta)
– Delta must be rising, confirming momentum
Acceleration > 0 (MACD Histogram on Delta)
– Delta must be accelerating in the same direction

Short entries use the exact inverse (all three < 0).

This drastically reduces VWAP-side chop and improves trend-continuation reliability.

2. NEW: Dedicated Momentum EMA Length Input ⚡
You can now independently control the EMA length used to calculate Delta momentum (Velocity).
This lets you tune the “responsiveness” of momentum without affecting MACD parameters.

No other behaviour, visuals, documentation, or threshold logic has been altered.
