RSI Divergence Entry Engine [trade_w_samet]🎯 RSI Divergence Entry Engine
RSI Divergence Entry Engine is a pivot-confirmed RSI divergence, optional trend-filtering, ATR-based trade-mapping, historical visualization, alert, and statistics indicator designed to help traders study how regular bullish and bearish RSI divergences can be converted into a structured chart workflow.
The script is built around one central idea:
A confirmed RSI divergence should be treated as analytical context first, and as a tracked trade setup only when the active direction filter and trade-state rules allow it.
The engine identifies regular RSI divergence between confirmed RSI pivots and corresponding price pivots.
When a divergence is confirmed, the script can:
• Display the divergence inside the RSI panel
• Fill the region between the RSI path and its divergence reference line
• Draw a three-layer neon divergence line directly between the corresponding price pivots on the main chart
• Evaluate the active trend-filter mode
• Open one tracked bullish or bearish setup when the signal is eligible
• Calculate an ATR-based Stop Loss
• Calculate TP1, TP2, and TP3
• Extend risk/reward boxes while the trade remains active
• Preserve completed trade boxes and historical TP price labels
• Track TP3 wins, Stop Losses, Win Rate, NET R, Average R, and Profit Factor
• Display a full desktop dashboard or a compact mobile dashboard
• Send separate TradingView alert conditions
• Support one combined “Any alert() function call” workflow
• Apply Dark Mode, Light Mode, or Mobile Theme styling
The indicator includes:
• Fixed RSI 14 calculation using closing prices
• Pivot-based regular bullish divergence detection
• Pivot-based regular bearish divergence detection
• Adjustable Pivot Lookback
• Adjustable Confirmation Bars
• A fixed internal pivot-distance window
• Confirmed-bar divergence acceptance
• RSI-panel bullish and bearish divergence lines
• RSI-panel divergence-area fills
• Main-chart three-layer neon divergence lines
• Adjustable main-chart BULLISH / SELL label size
• Fixed compact RSI-panel labels
• Dark Mode
• Light Mode
• Mobile Theme
• EMA 200 Trend Filter
• Supertrend filter using ATR 10 and factor 3.0
• Higher-timeframe EMA 200 Trend Filter
• Adjustable higher timeframe
• ATR-based Stop Loss
• Adjustable ATR period
• Adjustable ATR Stop Loss multiplier
• Adjustable TP3 target from 1R to 7R
• Automatically calculated TP1 and TP2
• One active tracked trade at a time
• Conservative same-candle TP3 / SL handling
• Permanent historical TP / SL boxes
• Historical TP1, TP2, and TP3 price labels
• Dynamic active-trade price labels
• TP3 TARGET HIT labels
• Stop Loss result labels
• Full desktop statistics dashboard
• Two-row Mobile Theme dashboard
• Static alertcondition() support
• Dynamic alert() support
• “Any alert() function call” compatibility
• Bold-italic visual text
• Pure-white Dark Mode label text
• Hidden status-line input values
• Main-chart overlay visuals from a separate RSI pane
• Loaded-history trade statistics
The purpose of the script is to provide a transparent visual framework for reviewing confirmed RSI divergence, directional context, mapped risk, target structure, and bar-based historical outcomes.
It is not financial advice.
It is not an automated trading system.
It does not execute broker orders.
It does not calculate position size.
It does not guarantee that a divergence will produce a reversal.
It does not guarantee that the displayed Win Rate, NET R, or Profit Factor will continue in future market conditions.
It does not include spread, commission, slippage, latency, financing, or partial fills.
It does not reproduce the exact intrabar path inside historical candles.
━━━━━━━━━━━━━━━━━━━━━━
📌 OVERVIEW
━━━━━━━━━━━━━━━━━━━━━━
At a high level, RSI Divergence Entry Engine does the following:
• Calculates RSI using a fixed 14-period length and closing prices.
• Searches the RSI series for confirmed pivot lows and pivot highs.
• Compares each confirmed RSI pivot with the previous eligible pivot of the same type.
• Compares the corresponding price low or high with the prior price pivot.
• Identifies regular bullish divergence when RSI forms a higher low while price forms a lower low.
• Identifies regular bearish divergence when RSI forms a lower high while price forms a higher high.
• Requires the distance between the two confirmed pivots to remain inside the fixed internal range window.
• Waits for the required right-side confirmation bars before accepting a pivot.
• Displays confirmed divergence inside the RSI panel.
• Draws the same confirmed price-pivot relationship on the main chart with a neon line.
• Evaluates the selected trend-filter mode.
• Rejects a tracked entry when the trend filter does not allow that direction.
• Rejects a tracked entry when an opposite divergence is simultaneously present.
• Rejects a tracked entry while another trade is active.
• Opens a tracked trade at the close of the divergence-confirmation candle.
• Calculates Stop Loss distance from ATR.
• Places TP1 and TP2 at proportional distances inside the final TP3 target.
• Tracks only TP3 as the winning exit.
• Tracks Stop Loss as a -1R loss.
• Extends the active profit and loss boxes until the trade closes.
• Preserves completed boxes as historical trade visuals.
• Preserves historical TP1, TP2, and TP3 price labels.
• Updates the dashboard with bar-based historical statistics.
• Provides separate static alerts and combined dynamic alerts.
The script does not use machine-learning prediction.
It does not claim that RSI divergence predicts the future with certainty.
Its dashboard is not TradingView Strategy Tester.
Its statistics are calculated internally from the script’s own bar-touch rules.
━━━━━━━━━━━━━━━━━━━━━━
🧠 CORE IDEA
━━━━━━━━━━━━━━━━━━━━━━
RSI divergence describes disagreement between price direction and RSI pivot direction.
A regular bullish divergence occurs when:
• price forms a lower low
• RSI forms a higher low
A regular bearish divergence occurs when:
• price forms a higher high
• RSI forms a lower high
The divergence can indicate that momentum is not confirming the newest price extreme.
However, divergence alone does not answer:
• whether the broader trend supports the reversal
• whether price is above or below a long-term directional reference
• whether Supertrend agrees with the signal
• whether the selected higher timeframe agrees with the signal
• where a volatility-adjusted Stop Loss should be mapped
• where intermediate and final targets should be displayed
• whether another tracked trade is already active
• whether historical bar touches reached TP3 or Stop Loss first
• how the signal behaves across Dark, Light, or Mobile layouts
The script therefore combines the divergence calculation with an optional trend filter and a fixed trade-tracking model.
The complete workflow is:
RSI pivot confirmation
→ price-pivot comparison
→ regular divergence confirmation
→ RSI-panel visualization
→ main-chart neon price-divergence line
→ optional trend-filter validation
→ one-active-trade check
→ entry at confirmation-candle close
→ ATR-based Stop Loss
→ TP1 / TP2 / TP3 mapping
→ historical bar-touch tracking
→ TP3 or SL result
→ dashboard statistics
→ static and dynamic alerts
The modules are not intended to operate as unrelated indicators.
Each module supports the same process: identifying a confirmed divergence, deciding whether it is eligible for tracking, mapping the trade structure, and recording the result under explicit rules.
━━━━━━━━━━━━━━━━━━━━━━
🧩 WHY THIS SCRIPT IS NOT A SIMPLE RSI DIVERGENCE MARKER
━━━━━━━━━━━━━━━━━━━━━━
A basic RSI divergence script can stop after drawing a line between two oscillator pivots.
RSI Divergence Entry Engine continues beyond that step.
A confirmed divergence can move through the following stages:
RSI pivot appears
→ right-side confirmation bars complete
→ previous eligible RSI pivot is located
→ pivot distance is validated
→ corresponding price pivots are compared
→ bullish or bearish divergence is confirmed
→ RSI divergence region is displayed
→ main-chart neon price-divergence line is displayed
→ active trend filter is evaluated
→ opposite-direction conflict is rejected
→ existing active-trade state is checked
→ ATR risk distance is calculated
→ entry, SL, TP1, TP2, and TP3 are stored
→ trade boxes extend through time
→ TP3 or SL is detected
→ completed trade is added to statistics
→ historical TP prices remain visible
The RSI module identifies the momentum disagreement.
The trend-filter module defines whether the tracked entry is directionally permitted.
The ATR module adapts the Stop Loss distance to current volatility.
The target module translates the chosen TP3 R multiple into three visual target levels.
The trade-state module prevents overlapping tracked positions.
The statistics module summarizes the outcomes produced by those exact rules.
The alert module communicates divergence, entry, TP3, and Stop Loss events.
This coordinated process makes the publication an entry-engine framework rather than only a divergence drawing tool.
━━━━━━━━━━━━━━━━━━━━━━
⚙️ HOW THE SCRIPT WORKS
━━━━━━━━━━━━━━━━━━━━━━
The indicator operates from a separate RSI pane while using force-overlay visuals for selected elements on the main chart.
The internal RSI configuration is:
• RSI length: 14
• Source: close
• Regular bullish divergence: enabled
• Regular bearish divergence: enabled
• Hidden bullish divergence: internally disabled
• Hidden bearish divergence: internally disabled
• Minimum pivot separation: 5 bars
• Maximum pivot separation: 60 bars
The user controls:
• Pivot Lookback
• Confirmation Bars
• Main-chart signal-label size
• ATR Period
• Stop Loss Distance in ATR
• TP3 Target in R
• Trend Filter
• Higher-Timeframe Trend Timeframe
• Theme Mode
First, the script calculates RSI:
osc = ta.rsi(close, 14)
The script then detects confirmed RSI pivots:
pivotLowValue = ta.pivotlow(osc, lbL, lbR)
pivotHighValue = ta.pivothigh(osc, lbL, lbR)
A pivot is not known on the pivot candle itself.
It becomes confirmed only after the selected Confirmation Bars have closed to its right.
The script then retrieves the previous confirmed pivot value, price value, and pivot bar.
Regular bullish divergence requires:
• current RSI pivot low above the previous RSI pivot low
• current price low below the previous price low
• valid pivot distance
• confirmed current chart bar
Regular bearish divergence requires:
• current RSI pivot high below the previous RSI pivot high
• current price high above the previous price high
• valid pivot distance
• confirmed current chart bar
The confirmed divergence is then displayed in two places:
• RSI pane
• Main price chart
The trend filter is applied only to the tracked trade entry.
This means a confirmed divergence can remain visible even when:
• the selected trend filter rejects the direction
• another trade is already active
• bullish and bearish conditions conflict on the same calculation
This separation is intentional.
The divergence visual represents analytical context.
The main-chart BULLISH or SELL trade label represents an entry that the tracking engine actually accepted.
━━━━━━━━━━━━━━━━━━━━━━
📉 RSI CALCULATION
━━━━━━━━━━━━━━━━━━━━━━
The Relative Strength Index is calculated from closing prices using a fixed length of 14.
The RSI line is displayed in blue.
The RSI pane includes:
• 70 Overbought line
• 50 Middle line
• 30 Oversold line
Dark Mode uses:
• black RSI-panel background
• red Overbought line
• white dotted Middle line
• green Oversold line
Light Mode uses:
• white RSI-panel background
• dark Middle line
• red Overbought line
• green Oversold line
The 70 and 30 lines provide visual context.
They are not mandatory divergence conditions.
A bullish divergence can be detected outside the Oversold region.
A bearish divergence can be detected outside the Overbought region.
The script does not require RSI to cross 30 or 70 before accepting a divergence.
━━━━━━━━━━━━━━━━━━━━━━
🔍 PIVOT DETECTION MODEL
━━━━━━━━━━━━━━━━━━━━━━
Pivot Lookback controls the number of candles examined on the left side of a potential RSI pivot.
The default value is 5.
Higher values generally produce larger and less frequent swing points.
Lower values generally produce smaller and more frequent swing points.
Confirmation Bars controls the number of completed candles required on the right side of the potential pivot.
The default value is 1.
A higher Confirmation Bars value provides more right-side confirmation but increases delay.
A lower value confirms earlier but can identify smaller structures.
The script also requires the previous pivot to be between 5 and 60 bars away.
These minimum and maximum distance values are fixed internally to keep the public settings panel compact.
The pivot model is symmetrical:
• pivot lows are used for bullish divergence
• pivot highs are used for bearish divergence
━━━━━━━━━━━━━━━━━━━━━━
🟢 REGULAR BULLISH DIVERGENCE
━━━━━━━━━━━━━━━━━━━━━━
A regular bullish divergence is confirmed when:
• a new RSI pivot low is confirmed
• the previous eligible RSI pivot low exists
• the current RSI pivot low is higher than the previous RSI pivot low
• the current corresponding price low is lower than the previous price low
• the pivot distance is between the fixed internal limits
• the current calculation bar is confirmed
Conceptually:
Price:
lower low
RSI:
higher low
The RSI pane displays:
• a green divergence line between the two RSI pivot values
• a translucent green fill between the real RSI path and the straight divergence reference
• a BULLISH label at the confirmed pivot location
The main chart displays:
• a three-layer green neon line between the corresponding price lows
A tracked bullish trade opens only when:
• the bullish divergence is not opposed by a bearish divergence on the same calculation
• the selected trend filter allows bullish entries
• no tracked trade is currently active
• another trade did not close on the same candle
• ATR is available and greater than zero
The tracked entry price is the close of the confirmation candle.
It is not the historical pivot-low price.
━━━━━━━━━━━━━━━━━━━━━━
🔴 REGULAR BEARISH DIVERGENCE
━━━━━━━━━━━━━━━━━━━━━━
A regular bearish divergence is confirmed when:
• a new RSI pivot high is confirmed
• the previous eligible RSI pivot high exists
• the current RSI pivot high is lower than the previous RSI pivot high
• the current corresponding price high is higher than the previous price high
• the pivot distance is between the fixed internal limits
• the current calculation bar is confirmed
Conceptually:
Price:
higher high
RSI:
lower high
The RSI pane displays:
• a red divergence line between the two RSI pivot values
• a translucent red fill between the real RSI path and the straight divergence reference
• a SELL label at the confirmed pivot location
The main chart displays:
• a three-layer red neon line between the corresponding price highs
A tracked bearish trade opens only when:
• the bearish divergence is not opposed by a bullish divergence on the same calculation
• the selected trend filter allows bearish entries
• no tracked trade is currently active
• another trade did not close on the same candle
• ATR is available and greater than zero
The tracked entry price is the close of the confirmation candle.
It is not the historical pivot-high price.
━━━━━━━━━━━━━━━━━━━━━━
⏳ PIVOT CONFIRMATION AND SIGNAL TIMING
━━━━━━━━━━━━━━━━━━━━━━
This section is important.
The script uses ta.pivotlow() and ta.pivothigh().
Pivot functions require candles to the right of the pivot before confirmation.
For example, when Confirmation Bars is 1:
• the potential pivot occurs
• one additional candle closes
• the pivot becomes confirmed
• the divergence condition can then be calculated
The RSI-panel divergence line and RSI divergence label are drawn at the original pivot-bar location after confirmation.
The main-chart neon divergence line also connects the original price-pivot bars after the divergence is confirmed.
This creates a historical visual relationship between the two pivots.
It does not mean the divergence was available in realtime on the original pivot candle.
The tracked trade entry is not placed back on the pivot.
The tracked entry occurs at the close of the later candle where the divergence confirmation becomes available.
Therefore, users must distinguish between:
Pivot Visualization
Shows where the confirmed historical pivots occurred.
Trade Entry Label
Shows the candle where the script actually accepted and opened the tracked setup.
Changing Confirmation Bars changes the confirmation delay.
Increasing Confirmation Bars can materially change signal timing and historical divergence output.
━━━━━━━━━━━━━━━━━━━━━━
✨ MAIN-CHART NEON DIVERGENCE VISUALS
━━━━━━━━━━━━━━━━━━━━━━
Confirmed RSI divergences are also displayed directly on the main price chart.
Bullish divergence:
• connects the two corresponding price lows
• uses green
• uses a three-layer neon appearance
Bearish divergence:
• connects the two corresponding price highs
• uses red
• uses a three-layer neon appearance
The neon effect is created from:
• a wide transparent outer glow
• a medium inner glow
• a bright two-pixel core line
The neon line is a historical divergence visual.
It is not an entry line.
It is not a Stop Loss.
It is not a support or resistance guarantee.
The line is created only after the RSI pivot and divergence have been confirmed.
Older line objects are removed when the configured internal object limit is exceeded.
Deleting an older visual object does not change the underlying signal calculation.
━━━━━━━━━━━━━━━━━━━━━━
🎨 RSI DIVERGENCE AREA SYSTEM
━━━━━━━━━━━━━━━━━━━━━━
Inside the RSI pane, the script creates a filled polygon between:
• the actual RSI path from the first pivot to the second pivot
• the straight divergence line connecting those pivot endpoints
Bullish divergence uses a translucent green fill.
Bearish divergence uses a translucent red fill.
The purpose is to make the momentum disagreement easier to recognize than a thin line alone.
The fill does not measure probability.
A larger visual area does not automatically mean a stronger or more profitable divergence.
The fill depends on:
• RSI movement between the pivots
• distance between the pivots
• selected Pivot Lookback
• selected Confirmation Bars
• chart symbol
• timeframe
• loaded historical data
━━━━━━━━━━━━━━━━━━━━━━
🧭 TREND FILTER SYSTEM
━━━━━━━━━━━━━━━━━━━━━━
The trend filter determines whether a confirmed divergence is eligible to open a tracked trade.
Available modes are:
• Off
• EMA Trend
• Supertrend
• HTF Trend
The filter does not hide the confirmed divergence visuals.
It only changes whether the trade engine accepts the bullish or bearish entry.
This allows users to study:
• all confirmed divergence structures
• only the subset that passed the selected directional filter
The active trend reference is drawn on the main chart when a filter mode is selected.
The reference is green when the active filter state is bullish.
The reference is red when the active filter state is bearish.
━━━━━━━━━━━━━━━━━━━━━━
📈 EMA TREND FILTER
━━━━━━━━━━━━━━━━━━━━━━
EMA Trend uses a fixed chart-timeframe EMA 200.
Bullish entries are allowed when:
• chart close is above EMA 200
Bearish entries are allowed when:
• chart close is below EMA 200
When price equals the EMA exactly, neither directional condition is satisfied.
The EMA filter is intended to align bullish divergence tracking with price above a long-term average and bearish divergence tracking with price below it.
It does not guarantee that price will continue in the filtered direction.
A divergence rejected by the EMA filter can still remain visible as a divergence visual.
━━━━━━━━━━━━━━━━━━━━━━
📊 SUPERTREND FILTER
━━━━━━━━━━━━━━━━━━━━━━
Supertrend mode uses fixed internal parameters:
• ATR length: 10
• factor: 3.0
Bullish entries are allowed when the Supertrend state is bullish.
Bearish entries are allowed when the Supertrend state is bearish.
The Supertrend reference is displayed on the main chart.
The fixed parameters keep the public settings menu simple and make behavior consistent across users.
The Supertrend filter can react differently across symbols and timeframes because ATR and price structure differ.
A bullish Supertrend state does not guarantee a successful bullish divergence trade.
A bearish Supertrend state does not guarantee a successful bearish divergence trade.
━━━━━━━━━━━━━━━━━━━━━━
⏱️ HIGHER-TIMEFRAME TREND FILTER
━━━━━━━━━━━━━━━━━━━━━━
HTF Trend compares the selected higher-timeframe close with its EMA 200.
Bullish entries are allowed when:
• higher-timeframe close is above higher-timeframe EMA 200
Bearish entries are allowed when:
• higher-timeframe close is below higher-timeframe EMA 200
The default higher timeframe is 240 minutes.
The request uses:
• gaps_off
• lookahead_off
The script does not intentionally request future higher-timeframe data.
However, the currently forming higher-timeframe candle can continue changing until that higher-timeframe candle closes.
This means the realtime HTF filter state can change while the active higher-timeframe candle is still developing.
Users who require fully closed higher-timeframe confirmation should account for this timing characteristic when interpreting realtime signals.
Changing the HTF Trend Timeframe recalculates historical eligibility.
━━━━━━━━━━━━━━━━━━━━━━
🎯 ENTRY MODEL
━━━━━━━━━━━━━━━━━━━━━━
The indicator uses the close of the divergence-confirmation candle as the tracked entry reference.
A bullish trade is opened when:
• valid bullish divergence is confirmed
• no bearish divergence conflict exists
• bullish trend permission is true
• no trade is active
• no trade closed on the same candle
• ATR is valid
A bearish trade uses the mirrored conditions.
The entry is stored at close.
The script then calculates:
• ATR-based risk distance
• Stop Loss
• TP1
• TP2
• TP3
Only signals that actually open a tracked trade receive the main-chart BULLISH or SELL entry label.
A divergence visual without an entry label can therefore indicate:
• trend-filter rejection
• existing active trade
• same-candle direction conflict
• same-candle previous trade closure
• unavailable ATR
━━━━━━━━━━━━━━━━━━━━━━
🛑 ATR STOP LOSS MODEL
━━━━━━━━━━━━━━━━━━━━━━
Risk distance is calculated as:
ATR × Stop Loss Distance.
Default settings:
• ATR Period: 14
• Stop Loss Distance: 2.0 ATR
Bullish trade:
Stop Loss = entry − risk distance
Bearish trade:
Stop Loss = entry + risk distance
ATR adapts the raw price distance to current market volatility.
The script does not examine:
• market structure below the bullish signal
• market structure above the bearish signal
• spread
• instrument tick value
• account size
• position size
• broker margin
• contract specifications
The ATR Stop Loss is a visual and statistical model.
It is not a broker order.
━━━━━━━━━━━━━━━━━━━━━━
🏆 TP1 / TP2 / TP3 MODEL
━━━━━━━━━━━━━━━━━━━━━━
The user selects the final TP3 target from 1R to 7R.
The default is 2R.
TP1 and TP2 are placed automatically inside the final target distance.
TP1:
one-third of the TP3 distance
TP2:
two-thirds of the TP3 distance
For a 3R TP3 setting:
• TP1 = 1R
• TP2 = 2R
• TP3 = 3R
For a 2R TP3 setting:
• TP1 ≈ 0.67R
• TP2 ≈ 1.33R
• TP3 = 2R
TP1 and TP2 are visual guide levels.
The current statistics engine does not close partial positions at TP1 or TP2.
It does not move Stop Loss to break even after TP1 or TP2.
It does not add partial R profit when TP1 or TP2 is touched.
Only TP3 is counted as a winning trade.
A Stop Loss is counted as -1R.
━━━━━━━━━━━━━━━━━━━━━━
🚦 ONE ACTIVE TRADE AT A TIME
━━━━━━━━━━━━━━━━━━━━━━
The trade engine maintains one active tracked position.
While a trade is active:
• new bullish divergence entries are not opened
• new bearish divergence entries are not opened
• divergence visuals can still appear
• historical divergence lines can still be drawn
This prevents overlapping tracked positions from affecting the statistics model.
A new trade is also prevented from opening on the same candle that the previous trade closes.
The next eligible divergence must occur on a later candle.
This design keeps each tracked result independent under the script’s internal accounting rules.
━━━━━━━━━━━━━━━━━━━━━━
⚠️ TP3 / SL SAME-CANDLE HANDLING
━━━━━━━━━━━━━━━━━━━━━━
Historical OHLC candles do not reveal the exact sequence of every intrabar price movement.
A candle can contain both:
• the TP3 price
• the Stop Loss price
When both are touched inside the same candle, the script cannot know from OHLC data which level occurred first.
The engine uses a conservative rule:
Stop Loss receives priority.
The trade is recorded as a loss.
TP3 and Stop Loss checks begin on the candle after entry.
The entry candle cannot immediately close the tracked trade.
This avoids assuming an unknown movement sequence inside the entry candle.
The conservative priority rule can produce different outcomes from lower-timeframe or tick-based execution reconstruction.
━━━━━━━━━━━━━━━━━━━━━━
📦 TRADE BOX VISUAL SYSTEM
━━━━━━━━━━━━━━━━━━━━━━
Each tracked trade creates two main-chart boxes:
Profit Box
Extends from entry to TP3.
Stop Box
Extends from entry to Stop Loss.
Bullish and bearish trades use the same green profit-area and red risk-area color logic.
While the trade remains active, the boxes extend to the current bar.
When the trade closes, the boxes stop at the exit candle and remain visible historically.
The boxes help visualize:
• entry timing
• risk distance
• final target distance
• trade duration
• exit candle
The boxes are chart drawings.
They are not broker orders.
Older boxes are deleted when the internal historical object limit is exceeded.
━━━━━━━━━━━━━━━━━━━━━━
🏷️ ACTIVE AND HISTORICAL PRICE LABELS
━━━━━━━━━━━━━━━━━━━━━━
During an active tracked trade, the right side of the chart displays dynamic labels for:
• ENTRY
• SL
• TP1
• TP2
• TP3
Each label includes the current stored price.
The labels move to the newest bar while the trade remains active.
On the exit candle, the final prices remain visible for that calculation.
When the trade closes, permanent historical labels are created for:
• TP1
• TP2
• TP3
These historical labels remain attached to the completed trade’s right edge.
The purpose is to preserve the target-price structure after the active dynamic labels disappear.
Historical TP labels do not indicate that TP1 or TP2 was actually touched.
They display the planned target prices for the completed tracked trade.
The final result is determined only by TP3 or Stop Loss.
━━━━━━━━━━━━━━━━━━━━━━
✅ RESULT LABELS
━━━━━━━━━━━━━━━━━━━━━━
When TP3 is reached, the script prints:
TARGET HIT
The trade is counted as a win equal to the selected TP3 R value.
When Stop Loss is reached, the script prints:
SL
The trade is counted as a -1R loss.
Result labels are displayed at the corresponding exit price.
All visible chart labels use bold-italic typography.
Dark Mode label text uses pure white.
Light Mode uses dark text where required for contrast.
━━━━━━━━━━━━━━━━━━━━━━
🎨 THEME SYSTEM
━━━━━━━━━━━━━━━━━━━━━━
The indicator includes three theme modes:
• Dark Mode
• Light Mode
• Mobile Theme
Dark Mode
Designed for dark TradingView layouts.
It uses:
• black RSI-panel background
• dark dashboard surface
• white dashboard text
• pure-white chart-label text
• red brand accents
• green bullish visuals
• red bearish visuals
Light Mode
Designed for light TradingView layouts.
It uses:
• white RSI-panel background
• white dashboard surface
• dark dashboard text
• dark chart-label text where appropriate
• red brand accents
• adjusted divergence transparency
Mobile Theme
Designed for smaller screens.
It uses:
• compact main-chart labels
• smaller RSI labels
• tiny price labels
• a two-row dashboard
• Win Rate
• NET R
Mobile Theme does not display the full desktop statistics table.
Theme selection changes presentation.
It does not change the underlying divergence, trend-filter, or trade calculations.
━━━━━━━━━━━━━━━━━━━━━━
📟 DASHBOARD
━━━━━━━━━━━━━━━━━━━━━━
Dark Mode and Light Mode display the full bottom-right dashboard.
The header displays:
• RSI DIVERGENCE
• selected TP3 R value
• active Trend Filter
The full dashboard includes:
Status
Possible values:
• NO ACTIVE TRADE
• ACTIVE BUY
• ACTIVE SELL
Closed Trades
Number of completed tracked trades.
TP3 Wins
Number of trades that reached TP3 before Stop Loss under the script’s bar-touch rules.
Losses
Number of trades recorded at Stop Loss.
Win Rate
TP3 Wins divided by Closed Trades.
NET R
Gross Profit R minus Gross Loss R.
Gross Profit
Sum of winning TP3 R values.
Gross Loss
Number of losing trades expressed as R because every Stop Loss equals -1R.
Average / Trade
NET R divided by Closed Trades.
Profit Factor
Gross Profit R divided by Gross Loss R.
Mobile Theme displays only:
• Win Rate
• NET R
The dashboard is placed on the main chart even though the indicator calculates in a separate RSI pane.
━━━━━━━━━━━━━━━━━━━━━━
📊 STATISTICS METHODOLOGY
━━━━━━━━━━━━━━━━━━━━━━
The statistics are produced by the script’s internal bar-based trade tracker.
They are not imported from a broker.
They are not verified account results.
They are not TradingView Strategy Tester results.
Win Rate:
wins / closed trades
Gross Profit R:
wins × selected TP3 R
Gross Loss R:
losses × 1R
NET R:
Gross Profit R − Gross Loss R
Average R:
NET R / closed trades
Profit Factor:
Gross Profit R / Gross Loss R
When there are profitable trades but no recorded losses, the script displays 999 as a finite placeholder instead of mathematical infinity.
The statistics do not include:
• TP1 partial profits
• TP2 partial profits
• break-even exits
• trailing stops
• spread
• commission
• slippage
• swap
• latency
• order rejection
• partial fills
• position sizing
• account equity
• compounding
• taxes
Statistics depend on:
• loaded chart history
• selected symbol
• timeframe
• data provider
• Pivot Lookback
• Confirmation Bars
• Trend Filter
• HTF Trend Timeframe
• ATR Period
• Stop Loss multiplier
• TP3 target
• historical-data revisions
Changing any of these inputs can change historical results.
━━━━━━━━━━━━━━━━━━━━━━
🚨 ALERT SYSTEM
━━━━━━━━━━━━━━━━━━━━━━
The script includes static TradingView alert conditions for:
• Regular Bullish Divergence
• Hidden Bullish Divergence
• Regular Bearish Divergence
• Hidden Bearish Divergence
• BUY Entry
• SELL Entry
• TP3 Hit
• Stop Loss Hit
Regular bullish and bearish divergence are enabled in the current public configuration.
Hidden bullish and hidden bearish divergence logic is internally disabled.
The hidden alert choices can therefore appear in TradingView’s alert-condition list, but no hidden divergence event is produced while the internal hidden-divergence switches remain disabled.
The script also includes dynamic alert() calls for:
• BUY entry
• SELL entry
• TP3 hit
• Stop Loss hit
Dynamic BUY and SELL messages can include:
• tradewsamet identifier
• chart ticker
• chart timeframe
• entry price
• TP1 price
• TP2 price
• TP3 price
• Stop Loss price
• final R target
• active Trend Filter
This allows one TradingView alert using:
Any alert() function call
to receive all dynamic entry and result events.
━━━━━━━━━━━━━━━━━━━━━━
🔔 HOW TO USE ALERTS
━━━━━━━━━━━━━━━━━━━━━━
For a specific static event:
1. Add RSI Divergence Entry Engine to the chart.
2. Open TradingView’s Create Alert window.
3. Select the indicator as the condition.
4. Choose the required event.
5. Select the notification method.
6. Use an appropriate frequency.
7. Test the alert before relying on it.
For one combined dynamic workflow:
1. Add the indicator to the chart.
2. Open Create Alert.
3. Select RSI Divergence Entry Engine .
4. Select Any alert() function call.
5. Configure the delivery method.
6. Test BUY, SELL, TP3, and SL message handling.
When the script, settings, symbol, or timeframe changes materially, recreate existing alerts.
A TradingView alert can continue using the script snapshot stored when the alert was created.
Alerts are monitoring tools.
They do not execute, modify, or close broker orders.
━━━━━━━━━━━━━━━━━━━━━━
🧪 HOW TO USE THE INDICATOR
━━━━━━━━━━━━━━━━━━━━━━
A practical workflow:
1. Add RSI Divergence Entry Engine to a standard candlestick chart.
2. Select Dark Mode, Light Mode, or Mobile Theme.
3. Begin with Pivot Lookback set to 5.
4. Begin with Confirmation Bars set to 1.
5. Observe the RSI-panel divergence structures.
6. Observe the matching neon price-pivot lines on the main chart.
7. Remember that the pivot visual becomes available only after right-side confirmation.
8. Distinguish the neon divergence line from the later tracked entry label.
9. Begin with Trend Filter set to Off when studying raw divergence frequency.
10. Test EMA Trend for chart-timeframe directional alignment.
11. Test Supertrend for volatility-based directional alignment.
12. Test HTF Trend for higher-timeframe EMA context.
13. Verify the selected HTF timeframe.
14. Review the main-chart trend reference.
15. Observe whether a BULLISH or SELL entry label is accepted.
16. Review ENTRY, SL, TP1, TP2, and TP3 prices.
17. Observe the profit and risk boxes.
18. Remember that TP1 and TP2 are visual only.
19. Review the final TARGET HIT or SL result.
20. Review dashboard Win Rate and NET R.
21. Compare Dark/Light full dashboard with Mobile Theme.
22. Use alerts for monitoring rather than blind execution.
23. Review broader market structure independently.
24. Review spread, liquidity, volatility, and news conditions.
25. Define personal account risk and position size.
26. Test the exact symbol, timeframe, and data feed personally used.
The indicator is designed for structured study and monitoring.
It should not be treated as an automatic decision-maker.
━━━━━━━━━━━━━━━━━━━━━━
⚙️ SETTINGS REFERENCE
━━━━━━━━━━━━━━━━━━━━━━
🎨 Theme
Theme Mode
Dark Mode
Uses the full dark visual profile.
Light Mode
Uses the full light visual profile.
Mobile Theme
Uses compact labels and a two-row dashboard.
━━━━━━━━━━━━━━━━━━━━━━
🎯 Signal Settings
Pivot Lookback
Controls the left-side pivot search width.
Default:
5
Higher values generally create larger and less frequent pivot structures.
Confirmation Bars
Controls the number of right-side completed candles required to confirm the RSI pivot.
Default:
1
Increasing the value increases confirmation delay.
Chart Signal Label Size
Controls the main-chart BULLISH and SELL entry-label size.
Available values:
• Tiny
• Small
• Normal
• Large
• Huge
Mobile Theme overrides the selected size with a compact layout.
━━━━━━━━━━━━━━━━━━━━━━
🧭 Trend Filter
Trend Filter
Available modes:
• Off
• EMA Trend
• Supertrend
• HTF Trend
Off
Allows tracked bullish and bearish entries without directional trend filtering.
EMA Trend
Uses chart close relative to EMA 200.
Supertrend
Uses ATR 10 and factor 3.0.
HTF Trend
Uses selected higher-timeframe close relative to higher-timeframe EMA 200.
HTF Trend Timeframe
Selects the higher timeframe used by HTF Trend.
Default:
240 minutes
This setting has no effect when HTF Trend is not selected.
━━━━━━━━━━━━━━━━━━━━━━
🛡️ Trade Management
ATR Period
Controls the ATR used for risk-distance calculations.
Default:
14
Stop Loss Distance (ATR)
Multiplies ATR to calculate the Stop Loss distance.
Default:
2.0
TP3 Target (R)
Selects the final target from 1R to 7R.
Default:
2R
TP1 and TP2 are calculated automatically from the TP3 distance.
All public input values are hidden from TradingView’s status line to reduce chart-header clutter.
━━━━━━━━━━━━━━━━━━━━━━
🧠 WHAT MAKES THIS SCRIPT ORIGINAL
━━━━━━━━━━━━━━━━━━━━━━
RSI, divergence, EMA, Supertrend, ATR, risk/reward targets, and trade statistics are established technical-analysis concepts.
These concepts are not unique by themselves.
The originality of RSI Divergence Entry Engine lies in the coordinated workflow applied to them:
fixed RSI calculation
→ confirmed oscillator pivots
→ price / RSI regular divergence comparison
→ pivot-distance validation
→ RSI-path divergence filling
→ main-chart three-layer neon pivot lines
→ optional chart or higher-timeframe trend filtering
→ one-active-trade state
→ confirmation-candle entry
→ ATR-normalized Stop Loss
→ proportional TP1 / TP2 placement
→ adjustable TP3 R target
→ conservative OHLC exit handling
→ permanent risk/reward history
→ historical target-price labels
→ theme-aware chart output
→ mobile-specific dashboard
→ internal R-based statistics
→ static and dynamic alert workflows
Distinctive implementation features include:
• separating divergence context from accepted tracked entries
• displaying the same confirmed divergence in the RSI pane and on the main chart
• filling the RSI path-to-divergence region
• using a three-layer neon price-divergence line
• preserving trade boxes after closure
• preserving TP1, TP2, and TP3 planned prices historically
• allowing multiple direction-filter models inside one entry workflow
• maintaining one tracked trade at a time
• applying conservative Stop Loss priority when TP3 and SL share a candle
• offering theme-specific dashboard behavior
• reducing the Mobile Theme dashboard to Win Rate and NET R
• supporting static conditions and combined dynamic alert() messages
• keeping public settings compact while documenting fixed internal values
The script is not a collection of unrelated indicators placed on one chart.
Every component supports the same objective: converting a confirmed RSI divergence into a transparent, filterable, volatility-mapped, historically reviewable entry framework.
━━━━━━━━━━━━━━━━━━━━━━
⚠️ IMPORTANT PRACTICAL NOTES
━━━━━━━━━━━━━━━━━━━━━━
Signal frequency depends on:
• symbol
• timeframe
• data provider
• Pivot Lookback
• Confirmation Bars
• fixed 5–60 bar pivot-distance window
• Trend Filter
• HTF Trend Timeframe
• existing active-trade state
• ATR availability
• available historical data
Higher Pivot Lookback values can reduce frequency.
Higher Confirmation Bars values increase delay.
EMA Trend can reject counter-position signals relative to EMA 200.
Supertrend can change direction after price movement.
HTF Trend can remain sensitive to the currently developing higher-timeframe candle.
Only one tracked trade can be active.
A divergence can therefore be visible without becoming a tracked trade.
TP1 and TP2 are not partial exits.
Historical TP1, TP2, and TP3 labels display planned prices, not proof that every level was touched.
Dashboard statistics use loaded chart history only.
Different brokers or exchanges can produce different:
• highs
• lows
• closes
• RSI pivots
• ATR values
• divergence signals
• trend-filter states
• TP3 / SL outcomes
• dashboard statistics
Changing the chart’s available history can change the first eligible pivot pair and all later trade-state sequencing.
━━━━━━━━━━━━━━━━━━━━━━
⚠️ LIMITATIONS AND SHORTCOMINGS
━━━━━━━━━━━━━━━━━━━━━━
This script has important limitations:
It does not guarantee profitable trades.
It does not predict future price movement.
It does not execute orders.
It does not place broker Stop Loss orders.
It does not place broker Take Profit orders.
It does not calculate position size.
It does not calculate account risk.
It does not include spread.
It does not include commission.
It does not include slippage.
It does not include latency.
It does not include swap or financing.
It does not model partial fills.
It does not model order rejection.
It does not model contract specifications.
It does not model tick-by-tick execution.
It uses historical OHLC bars.
It cannot always determine whether TP3 or SL occurred first inside one candle.
It resolves same-candle TP3 / SL ambiguity in favor of Stop Loss.
It does not record TP1 or TP2 as partial profit.
It does not move Stop Loss to break even.
It does not trail Stop Loss.
It maintains one active tracked trade.
It can ignore otherwise valid new entries while a trade is active.
It uses pivot confirmation.
Pivot visuals are not available on the original pivot candle in realtime.
RSI pivot visuals are placed at the historical pivot location after confirmation.
Main-chart neon lines are created after divergence confirmation.
The HTF filter can change while the current higher-timeframe candle remains open.
A confirmed divergence can fail.
A trend-aligned divergence can fail.
A larger divergence area does not guarantee a stronger result.
A neon divergence line is not guaranteed support or resistance.
A TARGET HIT label is not broker-verified execution.
Dashboard statistics are not audited performance.
Profit Factor displays 999 when wins exist without recorded losses.
Changing settings recalculates historical conditions.
Changing symbol, timeframe, provider, or available history can change output.
Alert delivery depends on TradingView and user configuration.
Alerts do not guarantee broker execution.
For these reasons, the indicator should be used as an educational decision-support and chart-review tool, not as a standalone automated strategy.
━━━━━━━━━━━━━━━━━━━━━━
👤 WHO THIS SCRIPT MAY BE USEFUL FOR
━━━━━━━━━━━━━━━━━━━━━━
This script may be useful for traders who:
• understand basic RSI divergence
• want regular bullish and bearish divergence visuals
• prefer pivot-confirmed structures
• want divergence displayed in both RSI and price
• want a clear neon main-chart divergence line
• want optional trend filtering
• use EMA 200
• use Supertrend
• use higher-timeframe direction
• want ATR-based risk mapping
• want adjustable R targets
• want historical risk/reward boxes
• want historical planned TP prices
• want one-active-trade statistics
• want Dark, Light, and Mobile themes
• want static alerts
• want one combined dynamic alert
• understand that chart statistics are not verified trading results
It may be less suitable for users who:
• want signals on the unconfirmed pivot candle
• want no pivot delay
• want hidden divergence enabled publicly
• want every divergence to open a trade
• want multiple overlapping tracked trades
• want partial TP accounting
• want automatic break-even management
• want trailing stops
• want tick-level backtesting
• want verified Strategy Tester results
• want broker execution
• want guaranteed reversal signals
• expect a high Win Rate to continue unchanged
• expect the HTF filter to remain fixed before the higher-timeframe candle closes
━━━━━━━━━━━━━━━━━━━━━━
🧭 BEST PRACTICE SUGGESTIONS
━━━━━━━━━━━━━━━━━━━━━━
For studying raw divergence behavior:
• use Trend Filter Off
• begin with Pivot Lookback 5
• begin with Confirmation Bars 1
• observe divergence visuals before evaluating trades
• distinguish pivot location from confirmation timing
For trend-aligned divergence:
• test EMA Trend
• test Supertrend
• compare signal frequency
• review whether the filter removes useful countertrend setups
For broader directional context:
• test HTF Trend
• use a higher timeframe meaningfully above the chart timeframe
• remember that the active HTF candle can change before closing
For trade mapping:
• begin with ATR 14
• begin with Stop Loss Distance 2.0 ATR
• begin with TP3 2R
• remember that TP1 and TP2 are visual only
• review same-candle TP3 / SL cases conservatively
For chart clarity:
• use Dark Mode on dark chart layouts
• use Light Mode on light chart layouts
• use Mobile Theme on small screens
• adjust the main-chart entry-label size
• use neon divergence lines as context, not automatic entries
Always:
• wait for divergence confirmation
• review broader price structure
• review liquidity and volatility
• review session conditions
• review news risk
• define personal account risk
• define personal position size
• test the exact symbol and timeframe
• verify alerts before relying on them
• remember that every divergence can fail
━━━━━━━━━━━━━━━━━━━━━━
🔓 PUBLICATION NOTE
━━━━━━━━━━━━━━━━━━━━━━
RSI Divergence Entry Engine is published as an educational RSI-divergence, directional-filtering, ATR trade-mapping, historical-visualization, and alert tool.
The purpose of this description is to explain:
• how RSI is calculated
• how RSI pivot lows and highs are confirmed
• how Pivot Lookback affects structure selection
• how Confirmation Bars affect delay
• how the fixed pivot-distance window works
• how regular bullish divergence is identified
• how regular bearish divergence is identified
• how divergence is displayed inside the RSI pane
• how the RSI divergence area is filled
• how corresponding price pivots are displayed with neon lines
• when the pivot visuals become available
• why pivot visuals appear at historical pivot locations
• why tracked entries are placed on confirmation-candle close
• how the trend filter affects entries without hiding divergence context
• how EMA Trend works
• how Supertrend works
• how HTF Trend works
• how currently forming higher-timeframe candles affect realtime context
• how ATR risk distance is calculated
• how Stop Loss is placed
• how TP1, TP2, and TP3 are calculated
• why TP1 and TP2 are visual only
• why only TP3 counts as a win
• how one-active-trade handling works
• how same-candle TP3 / SL ambiguity is resolved
• how historical trade boxes are retained
• what historical TP labels represent
• how Dark Mode, Light Mode, and Mobile Theme differ
• what the dashboard displays
• how Win Rate, NET R, Average R, and Profit Factor are calculated
• why the statistics are not broker-verified
• what static alert conditions are available
• how “Any alert() function call” works
• what the script does not simulate
• why the combined modules form one coordinated workflow
The script is designed to support structured review.
It does not promise profitable results.
It does not remove market risk.
It does not replace independent analysis.
It does not replace personal risk management.
━━━━━━━━━━━━━━━━━━━━━━
🕒 REPAINTING, BACKPLOTTING, AND TIMING DISCLOSURE
━━━━━━━━━━━━━━━━━━━━━━
RSI Divergence Entry Engine uses pivot functions.
Pivot confirmation requires future candles relative to the original pivot location.
The number of required right-side candles is controlled by Confirmation Bars.
The script does not know that a pivot exists on the original pivot candle.
After the right-side candles close:
• the pivot becomes confirmed
• the divergence can be calculated
• the RSI divergence line is displayed at the historical pivot locations
• the RSI divergence label is displayed at the confirmed pivot location
• the main-chart neon line connects the corresponding historical price pivots
This historical placement is a visual back-reference to the confirmed pivot structure.
It must not be interpreted as a realtime signal that was available on the original pivot candle.
The tracked trade entry is not backdated.
The tracked trade opens at the close of the later confirmation candle when all entry rules are valid.
The main-chart BULLISH or SELL entry label appears on that confirmation candle.
Trade outcome checks begin on the following candle.
The HTF Trend request uses lookahead_off.
It does not intentionally access future higher-timeframe values.
However, the current higher-timeframe candle can continue developing in realtime until it closes.
Historical results can change when:
• Pivot Lookback changes
• Confirmation Bars changes
• Trend Filter changes
• HTF Trend Timeframe changes
• ATR settings change
• TP3 target changes
• chart symbol changes
• timeframe changes
• exchange or broker feed changes
• historical data is revised
• available chart history changes
Confirmed chart-bar calculations reduce unfinished current-chart-candle changes.
They do not remove pivot confirmation delay, historical pivot placement, HTF live-candle variation, data-feed differences, or market risk.
━━━━━━━━━━━━━━━━━━━━━━
🛡️ DISCLAIMER
━━━━━━━━━━━━━━━━━━━━━━
RSI Divergence Entry Engine is provided for educational and informational purposes only.
It does not constitute financial, investment, trading, legal, accounting, or tax advice.
No indicator can guarantee future results.
Markets are uncertain.
Momentum changes.
Volatility changes.
Trend changes.
Liquidity changes.
Historical chart behavior does not ensure future performance.
Every user is responsible for their own:
• analysis
• validation
• symbol selection
• timeframe selection
• trend-filter selection
• execution planning
• Stop Loss placement
• target planning
• position sizing
• risk management
• alert configuration
• trading decisions
• broker execution
• legal obligations
• tax obligations
The RSI pivots, divergence lines, divergence fills, neon price-pivot lines, trend references, BULLISH labels, SELL labels, ENTRY labels, Stop Loss levels, TP1 levels, TP2 levels, TP3 levels, trade boxes, historical target labels, TARGET HIT labels, SL labels, dashboard statistics, Win Rate, NET R, Average R, Profit Factor, and alerts are visual analysis tools only.
A bullish divergence is not a guaranteed reversal.
A bearish divergence is not a guaranteed reversal.
An EMA-aligned signal is not guaranteed to succeed.
A Supertrend-aligned signal is not guaranteed to succeed.
A higher-timeframe aligned signal is not guaranteed to succeed.
A TARGET HIT label is not proof of an actual broker fill.
An SL label is not proof of an actual broker fill.
The dashboard is not verified account performance.
The statistics are not audited.
The script does not include spread, commission, slippage, latency, financing, partial fills, order rejection, position sizing, account equity, or broker-specific execution behavior.
Use the script as a structured RSI-divergence review, directional-filtering, trade-mapping, and monitoring framework—not as a promise of profitability or a substitute for independent judgment.
Penunjuk
Dynamic Market Metrics [MarkitTick]💡 All-in-one market analysis suite designed to unify trend evaluation, momentum measurement, and dynamic risk management into a single, cohesive interface. Rather than relying on a scattered array of disparate indicators, this unified system synthesizes multiple dimensions of market data—including volatility, money flow, and higher-timeframe confluence—to provide a comprehensive structural overview of the current asset. It visually maps trend direction, plots actionable trade risk levels, and features a real-time heads-up display (HUD) dashboard to track critical market internals without cluttering the charting workspace.
● Overview
✨ Originality and Utility
Traditional technical analysis often forces traders to compromise between lagging trend followers and noisy momentum oscillators. This script solves that divergence by integrating an adaptive trend baseline with volume-weighted momentum constraints. It is unique in its ability to automatically map forward-looking risk-to-reward brackets the moment a structural shift is confirmed. Instead of guessing where to place stops and targets, the system calculates these thresholds dynamically based on real-time volatility, offering a strictly objective framework for trade management. This eliminates the need for messy chart mashups, replacing them with a highly organized, singular logic engine.
🔬 Methodology and Concepts
The core engine of this tool operates on an abstracted synthesis of price volatility and money flow dynamics.
The primary trend anchor is established by evaluating average true price ranges against the flow of capital entering or exiting the asset.
Rather than relying on simple price crosses, the baseline only shifts when confirmed by underlying volume and momentum pressures.
A specialized breakout override mechanism constantly monitors for abnormal momentum spikes. If a sudden surge in directional velocity exceeds the baseline volatility threshold, the system immediately recalculates the trend state to adapt to the new market structure.
Trade levels are generated using a dynamic risk parity model. The system measures the precise distance between the confirmed entry trigger and the structural invalidation point, projecting synchronized target tiers that maintain strict mathematical risk-to-reward ratios.
All higher-timeframe data integration is strictly coded using offset historical referencing, ensuring absolute data integrity and preventing any future leakage or repainting artifacts.
🎨 Visual Guide
The script utilizes a clean, professional aesthetic, heavily reliant on dynamic colors and structured dashboard elements.
• The Trend Anchor and Cloud
Trend Line: A distinct, segmented line that tracks the primary market direction. It colors dynamically based on the active state (Bullish, Bearish, or Neutral).
Dynamic Cloud: A semi-transparent filled area bridging the primary trend line and a smoothed reference baseline. The thickness of this cloud visually represents the immediate strength and momentum of the trend.
Candle Coloring: Chart candles are painted to match the active trend state, providing instant visual alignment with the underlying engine.
• Trade Levels and Signals
Signal Markers: Minimalist labels appear above or below the price action to indicate confirmed structural shifts.
Stop Loss (SL) Line: A solid line representing the exact invalidation point of the active trend.
Entry Line: A dashed line marking the exact price where the signal was confirmed.
Take Profit (TP) Lines: A series of three dashed lines representing incremental target zones.
Risk/Reward Fills: Shaded background zones visually map the risk area (Entry to SL) against the reward area (Entry to TP3), allowing for immediate visual risk assessment.
• The HUD Dashboard
Located in the top right corner, this data table provides a real-time read of market internals:
Trend State & HTF Context: Displays the current directional bias on both the local and higher timeframes.
Entry, Target, and SL: Prints the exact numerical values for the active trade parameters.
Momentum & Money Flow: Visual progress bars indicating the current intensity of price movement and capital flow.
Volatility: Indicates whether the market is currently in a state of expansion or contraction.
Trend Age: A counter showing exactly how many bars have elapsed since the current trend began.
📖 How to Use
The system is designed to be highly objective. Monitor the chart for a confirmed signal marker, which indicates a shift in the underlying structural trend. Once a signal fires, the script will automatically render the Entry, Stop Loss, and Take Profit levels.
Validation: Before considering the signal, check the HUD Dashboard. A high Momentum score and an aligned Higher Timeframe (HTF) Context significantly increase the probability of continuation.
Execution: Use the exact printed Entry line for placement. The Stop Loss line dictates the hard invalidation point where the premise of the trend is broken.
Management: As price moves in the anticipated direction, manage the position by scaling out or moving protective stops as the asset crosses the TP1, TP2, and TP3 thresholds.
Breakouts: If a sudden momentum burst triggers an override, the trend state will flip immediately. Treat these as aggressive volatility expansions that require tighter risk management.
⚙️ Inputs and Settings
The settings panel is modularized for precise user control:
• Core & Breakout
ATR Mult & Length: Adjusts the core sensitivity of the volatility engine. Lower values create a tighter, more reactive baseline.
BO Override & Sens: Toggles the momentum breakout detection and dictates how much abnormal velocity is required to override the primary trend.
• Higher Timeframe (HTF)
Show HTF & TF: Enables the integration of a secondary, longer-term timeframe to act as a directional filter.
• Trade Tools & Cloud
Show Trade Levels: Toggles the rendering of the dynamic Entry, SL, and TP lines.
Cloud Settings: Controls the length, transparency, and rendering of the visual trend cloud and candle coloring.
• Alerts & Colors
JSON Action Strings: Allows users to input custom formatted strings for Long, Short, and Close actions, perfectly integrating with automated third-party execution platforms.
Colors: Fully customizable palettes for all lines, fills, dashboards, and signal markers.
🔍 Deconstruction of the Underlying Scientific and Academic Framework
The architectural foundation of this system rests on auction market theory and the statistical properties of volatility clustering. Financial markets operate through continuous auctions where price discovery is driven by the aggressive absorption of resting liquidity. This engine abstracts that process by measuring the standard deviation of price excursions—quantifying the asset's true range—and mapping it against the directional flow of capital.
By analyzing the divergence between pure price action and volume-weighted accumulation, the system identifies the true mean of value. When price deviates beyond these statistical bounds accompanied by extreme momentum, it signals a structural paradigm shift rather than a standard mean-reversion event. Furthermore, the embedded risk parity model abandons static numerical thresholds in favor of dynamic proportional scaling. The reward brackets are continuously mathematically linked to the localized volatility of the anchor point, ensuring that the risk-to-reward distribution remains statistically constant regardless of the asset's current expansion or contraction phase.
⚠️ Disclaimer
All provided scripts and indicators are strictly for educational exploration and must not be interpreted as financial advice or a recommendation to execute trades. We expressly disclaim all liability for any financial losses or damages that may result, directly or indirectly, from the reliance on or application of these tools. Market participation carries inherent risk where past performance never guarantees future returns, leaving all investment decisions and due diligence solely at your own discretion. Penunjuk
FVG Sniper [JOAT]═══ FVG SNIPER ═══
A complete Fair Value Gap engine that finds price imbalances, grades their quality, tracks how they fill, mitigate and invert, and then paints a full trade blueprint the moment a clean setup fires. One gap is spotlighted as the strongest, and every signal arrives with entry, three targets, a stop, and colored risk/reward zones — no arrows, no clutter.
▎ WHAT IT DOES
FVG Sniper detects three-candle fair value gaps (imbalances), scores each one from 0–10, and monitors its life cycle: how much of the gap has been filled, whether it has been mitigated (wick-tapped through), and whether price has closed fully through it to flip its role into an Inverted FVG (IFVG) . When a graded gap produces a rejection or an IFVG flip that agrees with the higher-timeframe bias, it draws a structured trade plan and reports the whole picture in a dashboard.
▎ HOW IT WORKS
• Gap detection — a bullish gap forms when the current low sits above the high from two bars back; a bearish gap forms when the current high sits below the low from two bars back.
• Quality filters — each candidate must clear a minimum gap size (as a multiple of ATR ) and a minimum displacement body ratio on the impulse candle, so tiny or weak imbalances are ignored.
• Grade (0–10) — blends gap size, the displacement range of the middle candle, and relative volume into a single score. Only gaps at or above your minimum grade may fire a signal.
• Fill & mitigation — the engine tracks the running extreme inside each gap to compute a live fill percentage, and marks a gap mitigated once a wick fully traverses it.
• Inversion (IFVG) — when price closes fully through a gap, its role flips; the box restyles to a dashed amber accent and the flip is logged.
• Signals — two sources you can mix or isolate: Rejection (price retraces into a live gap and reacts back out with a directional close) and IFVG Flip (a mitigated gap is closed through, confirming continuation).
• HTF bias filter — an optional higher-timeframe EMA bias must agree with the signal direction before it is allowed.
• Trade model — on a fresh signal it sets entry at close, a stop either gap-protected (just beyond the triggering gap boundary) or ATR-based, with risk clamped between a floor and a cap. Targets TP1/TP2/TP3 are placed at your chosen R multiples.
• Non-repainting — all detection, scoring and signals evaluate on confirmed (closed) bars only, and the HTF request uses no lookahead.
▎ HOW TO USE IT
• Trade in the direction of the BUY / SELL pill. The stars and score on the pill show the grade of the gap that triggered it.
• The entry line (chrome), dashed stop , and TP1/TP2/TP3 lines map the plan directly on the chart; level labels on the right print exact prices and R values.
• The green zone is the target/reward area from entry to TP3; the red zone is the risk area between entry and stop — a fast visual read of the trade's R:R.
• A single ★ spotlight tags only the strongest active gap, so you always know the best imbalance in view.
• Use live gaps as decision zones: watch the fill % of the nearest gap, and treat an IFVG flip as a shift in short-term control.
• When a trade closes, a result label prints the outcome (TP hit, stop, or exit at R) so completed setups stay readable.
• Combine with your own structure, session and news context — the gap engine locates the where , you confirm the when .
▎ KEY SETTINGS
• Engine — enable bullish/bearish detection, choose the signal source (Rejection, IFVG Flip, or both), and cap how many gaps stay visible plus their lifetime and box extension.
• Filters — ATR length, minimum gap size, minimum displacement body ratio, minimum grade, the HTF bias filter (timeframe + EMA length), and whether a directional rejection close is required.
• Trade Model — stop basis (Gap-Protected vs ATR), stop buffer/distance, risk floor and cap, TP1–TP3 in R, max trade duration, zone projection, and how many completed trades to keep.
• Visuals — toggle gap boxes, midline, hide-mitigated declutter, grade spotlight, IFVG styling, signal pills, zone boxes, lines, level and result labels, zone-reader candle coloring, optional VWAP + σ bands, and all colors/transparency/sizes.
• Dashboard — show/hide, position, text size, and dark or light panel.
▎ DASHBOARD
The on-chart panel reports: HTF bias, count of active bullish and bearish gaps, the nearest gap price and its fill %, the strongest gap's star grade, the last IFVG flip (with bar age), the active signal, any live trade with its entry, and running totals of bullish / bearish / inverted gaps detected.
▎ ALERTS
• BUY signal
• SELL signal
• Bullish IFVG Flip (inversion up)
• Bearish IFVG Flip (inversion down)
▎ NOTES
• Works on all timeframes and all assets — indices, forex, crypto, stocks, futures.
• Signals and drawings are computed on closed bars, so they do not repaint after the bar confirms.
• Object caps and hide-mitigated / declutter toggles keep the chart clean even on long histories.
• Any on-chart result labels reflect historical signals only and are illustrative, not a performance guarantee.
For research and education only. This is not financial advice. No indicator can predict the future, and past behavior does not guarantee future results — always manage your own risk.
Made with passion by JackOfAllTrades ⚡
Penunjuk
Penunjuk
IQ Trend Beams [TradingIQ]🔹 OVERVIEW
IQ Trend Beams is a trend assistant that draws your trendlines the way a disciplined chartist would - and then holds them accountable. It maintains two channels, support and resistance , each always showing one working line. A line is born forming : it moves and re-shapes freely, polished every bar by a perceptual score toward the line a skilled trader would actually draw. When its geometry settles and it has earned enough tangency credit, it locks - and from that moment the ink is frozen forever; it never moves again. Locked ink extends until break evidence fires, then it is broken : restyled but never relocated, holding the screen as history until its successor locks.
Riding each live beam is its own forecast ; a calibration band, a reach profile, and ghost levels, all built from the volume that has actually traded around that line.
This is an honest visualization and modeling tool , not a signal service. It draws structure clearly and states its own confidence out loud; it is not a validated edge or a promise of profit. Read the limitations section - it is not window dressing.
🔹 THE TWO CHANNELS - AN AUDITED PROMISE
Most trendline tools quietly redraw the past so the line always looks right in hindsight. Trend Beams refuses to. A line lives through three visible states:
• Forming (dotted) - the assistant sketching. It is free to move and re-fit while it hunts for the right geometry. This is the only state in which a support/resistance line moves, and it is dotted precisely so you can tell a guess from a commitment.
• Locked (solid) - the geometry has stilled and earned its tangency credit, so the line is frozen . It will never move again. A locked beam is a promise the tool has to keep in public.
• Broken (restyled) - break evidence fired. The ink is re-styled to show it failed, but it is never relocated ; it holds its original slope as an honest record and, if you keep history on, dims into the background once its successor locks.
Because a locked line cannot move, what you saw at lock time is what you keep. This is the core design commitment of the tool.
Two rails, either direction by design. Support is the lower rail, fit to the swing lows on the underside of price; resistance is the upper rail, fit to the swing highs above it. Neither is locked to a single slope: in a falling market the support rail angles down with the lows (the floor of the down-channel), and in a rally the resistance rail angles up with the highs (the ceiling of the up-channel). That is deliberate. A tool that forces support to only ever point up would go blind to the lower boundary of a downtrend - and miss exactly the moves that matter. Trend Beams instead always draws both boundaries of the channel price is actually in , so a strong move is framed on both sides rather than half-missed. If you prefer to read it the classical way, follow the rail that agrees with the trend and treat the other as the opposite wall of the same channel.
🔸 HOW A LINE EARNS ITS LOCK
While forming, each line is scored every bar by a perceptual fit , a running measure of how well its geometry matches what a careful trader would draw against the recent swing structure, blended with a one-pole toward its fitted slope so it settles rather than twitches. A lock is granted only when the geometry has gone still for long enough, the line has accumulated real tangency credit (genuine touches, not a single graze), and it spans a minimum bar count - and it is refused outright if it would invert the channel. The Mode dial sets how much evidence this takes.
🔹 THE AUDIT BADGE
Locked ink can carry a small measurement badge that reports, in plain terms, how the line is actually holding up:
• Wick-through - recent piercing of the line, exponentially weighted, measured against the tool's 10% design target . A well-behaved line lets price kiss it, not knife through it.
• Survival probability - the current modeled odds that the line is still valid.
• Maturity - how far through its estimated total run the move is, so a young trend reads differently from an exhausted one.
The badge is the tool grading its own work on the chart, not a trade instruction.
🔸 THE FORECAST - EACH BEAM READS ITS OWN VOLUME
Every live beam carries its own forecast, built entirely from the volume that has traded around that line. Trend Beams bins the intrabar volume by its distance from the beam, smooths it into a continuous density (a kernel-density estimate), and renders three things that ride the line:
• Calibration band - translucent ribbons hugging the beam, one per density bin, showing where the trend has held its volume. Strength is encoded as colour vibrancy at a constant perceptual lightness (the Oklab principle - a dense core reads vivid, the thin tails fade), so nothing is made brighter or darker than its weight warrants.
• Reach profile - a smooth filled contour fanning into the future margin, where each level's forward extent is its density times the trend's estimated remaining length . It answers, at a glance: if this trend keeps going, how far - and around which prices - does its own volume say it reaches?
• Ghost levels - dashed lines at the distribution's densest peaks, riding parallel to the beam, marking the prices this trend keeps returning to.
The forecast attaches only to a beam's currently-visible live element - its forming sketch, or its locked ink - and keeps no history . It is a read of the present trend, refreshed at the live edge, not a replay of the past.
🔸 THE ENGINE DIALS
• Mode - the tempo. Fast locks, breaks and re-forms sooner (short swings); Slow demands more evidence and holds through more noise (long moves); Medium is the balanced reference.
• Precision - how much data the engine reads: the perceptual fit window and the intrabar sample rate. Higher tiers resolve finer structure at more load. Sampling is timeframe-aware and never drops below one minute.
🔹 LAYERS, COLOUR & LEGIBILITY
Every layer is a toggle - forming lines, broken history, audit badges, and the forecast - so you can run it as a bare two-line channel or a fully dressed read. Colours come from three clean anchors: Support , Resistance , and Chrome (badges and neutral furniture). The whole translucent forecast - band, profile, and ghost levels - is coloured in the Oklab perceptual space, so strength shows up as vibrancy at a constant lightness rather than as glare, and a single Contrast dial scales the entire forecast from a whisper to bold.
🔸 HOW TO READ IT
• Treat a forming (dotted) line as a hypothesis and a locked (solid) line as a committed level - the tool is telling you which is which on purpose.
• Watch the audit badge : rising wick-through and falling survival probability say a locked line is wearing out.
• Read a broken line as a failed level that still marks where the structure gave way.
• Use each beam's band to see where its trend has held its volume, its reach profile for how far the trend's own volume says it can run, and its ghost levels for the prices it keeps returning to.
🔹 INPUTS
• Trend Engine - Mode (tempo) and Precision (data depth).
• Layers - show forming lines, broken history, audit badges, and the forecast.
• Colors - Support, Resistance, and Chrome anchors, plus a Contrast control for the translucent forecast.
• Channels - enable the support and/or resistance side independently.
🔸 LIMITATIONS AND HONEST NOTES
• This is a drawing and modeling assistant , not a validated strategy. It makes no performance claim and no edge claim . Nothing here is financial, investment or trading advice.
• Locked and broken lines do not repaint - once a line locks, its geometry is frozen. Forming lines move by design (they are the live sketch, and are dotted to say so), and each beam's forecast (band, profile, ghost levels) refreshes at the live edge as new volume arrives and attaches only to the current live element. These are live reads, on purpose; none of them rewrites confirmed history.
• Survival probability, maturity, remaining length and the reach profile are model estimates from the trend's own statistics - projections, not guarantees, and not forecasts of price.
• Intrabar sampling is subject to your plan's intrabar data limits ; higher Precision tiers read more intrabar data.
• Drawing budgets are finite. The tool caps its lines, labels and polylines internally, but very long histories with everything enabled push against TradingView's per-script drawing limits - trim the layers you don't need.
Penunjuk
Auto Target Pro◆➤OVERVIEW
Auto Target Pro v6 is a professional TradingView indicator designed to help traders manage entries, stop loss, and profit targets with a structured approach.
The indicator combines trend analysis, volatility measurement, and risk-based target calculation to provide a complete trade management system directly on the chart.
Auto Target Pro helps traders visualize potential entry points, risk levels, and multiple profit targets without manually calculating every level.
◆➤FEATURES
• Automatic BUY and SELL signals
• Dynamic Entry price calculation
• ATR-based Stop Loss system
• Automatic TP1, TP2, and TP3 levels
• Risk-to-Reward based target projection
• Real-time trade management
• Visual Entry, Stop Loss, and Target lines
• Target hit detection system
• Professional dashboard display
• Alert support for signals and targets
• Works on Forex, Crypto, Stocks, Indices, and Commodities
• Designed for scalping, intraday, and swing trading
◆➤HOW IT WORKS
Auto Target Pro uses a combination of trend structure and volatility analysis.
The system identifies market direction using trend calculations and detects potential trading opportunities.
After a signal appears:
◆➤BUY Setup:
Entry price is calculated automatically
Stop Loss is placed using market volatility
TP1, TP2, and TP3 are calculated based on risk distance
◆➤SELL Setup:
Entry price is calculated automatically
Stop Loss is adjusted according to bearish conditions
Multiple profit targets are displayed automatically
The target levels are dynamic and adapt according to current market conditions.
◆➤HOW TO USE
Add Auto Target Pro v6 to your TradingView chart.
Select your preferred timeframe according to your trading style:
Scalping: 1m, 5m, 15m
Intraday: 30m, 1H
Swing Trading: 4H, Daily
Wait for BUY or SELL confirmation.
Use the displayed levels:
Entry = Trade activation area
SL = Risk protection level
TP1 = First profit target
TP2 = Second profit target
TP3 = Final target area
Always combine signals with proper risk management and your own market analysis.
◆➤IMPORTANT NOTE
Auto Target Pro is a technical analysis tool created to assist traders in decision-making. No indicator can guarantee future market results. Always use proper risk management before entering any trade. Penunjuk
Penunjuk
Penunjuk
Institutional Gradient ChannelInstitutional Gradient Channel
tradingview.com
Institutional Gradient Channel is a comprehensive institutional market analysis indicator designed to help traders understand trend direction, market structure, institutional participation, price location, momentum quality, and potential continuation or reversal opportunities from a single integrated trading framework. Rather than relying on a single technical indicator, it combines multiple analytical models into one unified environment so traders can evaluate the overall condition of the market before making trading decisions.
The primary objective of this indicator is to simplify institutional-style chart analysis. Professional traders rarely make decisions based on one signal alone. They study trend direction, price position, market structure, liquidity, momentum, volatility, volume behavior, and reaction zones simultaneously. Institutional Gradient Channel brings these concepts together into a single visual framework that remains clean, organized, and easy to interpret during live market conditions.
The indicator continuously evaluates price action using an adaptive gradient channel that automatically adjusts to changing market conditions. As volatility expands or contracts, the channel responds dynamically to maintain a realistic representation of the current trading environment. This allows traders to immediately recognize whether price is trending strongly, moving within equilibrium, approaching potential resistance, or trading near areas where institutional reactions may become more likely.
One of the core features of the indicator is its institutional gradient channel. Instead of displaying a simple static trend line, the channel provides a dynamic visual representation of market direction while highlighting the relative position of price within the current trend. As price approaches the upper portion of the channel, traders can evaluate whether buying pressure remains healthy or whether momentum may be weakening. Likewise, movement toward the lower portion of the channel may indicate increasing selling pressure or developing opportunities for bullish recovery depending on surrounding market conditions.
The indicator also performs continuous market structure analysis. Every new swing is evaluated to determine whether the market is producing Higher Highs, Higher Lows, Lower Highs, or Lower Lows. Breaks in market structure are identified to help traders recognize transitions between bullish and bearish environments. This enables traders to understand whether the prevailing trend remains intact or whether institutional order flow may be beginning to shift in the opposite direction.
Trend quality is measured through multiple internal calculations rather than a single moving average. Momentum, directional persistence, volatility, and structural behavior are combined to estimate the overall strength of the current trend. Instead of simply showing whether price is rising or falling, the indicator attempts to determine how healthy and sustainable the trend currently appears.
Another important component is the institutional order flow analysis. While true exchange order flow data is not available for many markets, the indicator estimates buying and selling participation by analyzing price movement, candle behavior, volatility, and relative volume. These measurements provide traders with an approximation of whether buyers or sellers currently maintain stronger control over market direction.
The volume profile section enhances the analysis by identifying areas where market activity has concentrated over the selected analysis period. The developing Point of Control, Value Area, and high-volume regions help traders understand where institutional participation has historically been strongest. These areas frequently act as important reaction zones where price may pause, consolidate, reverse, or continue depending on broader market conditions.
Institutional Gradient Channel also continuously evaluates price location relative to the overall trading environment. It determines whether price is positioned inside premium territory, discount territory, or near equilibrium. This information helps traders avoid chasing extended moves and instead focus on locations where risk and reward may become more favorable.
Support and resistance levels are generated dynamically rather than remaining fixed. As market conditions evolve, the indicator updates important boundaries using current price behavior, trend development, structural analysis, and institutional positioning. These adaptive levels help traders monitor potential reaction zones without requiring constant manual chart adjustments.
The scenario projection engine provides an estimated continuation pathway based on the current market environment. Rather than attempting to predict the future with certainty, it illustrates a logical sequence of possible market development including trigger zones, retest opportunities, continuation areas, projected targets, and potential extension levels. This allows traders to prepare for multiple outcomes while maintaining flexibility as new price information becomes available.
The integrated dashboard serves as a centralized decision-making panel by summarizing the most important market information in real time. It continuously updates values such as market bias, trend strength, channel position, institutional participation, price location, momentum quality, compression level, volume profile statistics, structural status, and scenario direction. Instead of scanning multiple indicators across the chart, traders can quickly assess overall market conditions from a single organized interface.
This indicator is designed to support discretionary trading rather than replace proper market analysis. It performs best when its institutional framework is combined with disciplined risk management, higher timeframe confirmation, and sound trading principles. The generated information should be interpreted as analytical guidance intended to assist decision-making rather than as guaranteed buy or sell instructions.
Institutional Gradient Channel was developed to provide traders with a professional-grade institutional analysis framework that remains visually organized while delivering meaningful insight into changing market conditions. The objective is to reduce chart clutter, improve market awareness, and help traders evaluate trend quality, institutional positioning, and structural behavior through one integrated analytical environment suitable for Forex, Gold, Indices, Stocks, Futures, and Cryptocurrency markets across multiple timeframes.
Verification and Clarification
Author: Forex_Market_Insights
This indicator has been independently designed, engineered, and implemented by Forex_Market_Insights. Every analytical component, calculation method, visualization system, dashboard element, market structure model, trend evaluation process, channel construction technique, volume interpretation method, projection framework, and internal programming architecture has been developed specifically for this project using original implementation methods.
Although the indicator utilizes analytical concepts that are widely recognized throughout technical analysis, including trend channels, regression analysis, market structure, support and resistance, volume profile concepts, momentum evaluation, volatility measurements, and institutional trading principles, the software implementation itself has been independently engineered from the ground up.
This script is not intended to reproduce, imitate, reverse engineer, translate, decompile, modify, or derive from the protected implementation of any commercial, invite-only, private, open-source, or publicly available TradingView indicator. Similarity in trading concepts reflects the common nature of financial market analysis and should not be interpreted as similarity in programming implementation or software architecture.
Forex_Market_Insights declares that this indicator represents an original software development project created through independent research, engineering, and Pine Script programming practices. Every calculation, visual component, dashboard system, analytical module, and processing routine has been designed to operate as part of a self-contained institutional trading framework developed specifically for this indicator.
The purpose of publishing this script is to provide traders with a professional institutional market analysis tool that emphasizes clarity, transparency, maintainability, performance, and independent software engineering while delivering meaningful market insight through an original Pine Script implementation.
tradingview.com Penunjuk
Titan Algo | PropTraderz
Titan Algo | PropTraderz is an all-in-one technical analysis indicator designed to help traders identify market direction, trend strength, potential Buy/Sell signals, and important trading levels.
Main features:
• Supertrend-based Buy and Sell signals
• Optional Smart Signals using the 200 EMA trend filter
• Multi-timeframe dashboard for M1, M5, M15, M30, 1H, 4H, and D1
• Bar Coloring modes: Gradient, Trend, or None
• Trend Cloud, Trend Follower, Cumulus Cloud, and Cirrus Cloud
• Smart Trail and dynamic trend lines
• Support and Resistance zones
• Supply and Demand areas
• ATR-based Entry, Stop Loss, and Take Profit levels
• 1:1, 2:1, and 3:1 risk-reward targets
• Buy and Sell alerts
• Adjustable sensitivity and risk-management settings
This indicator is intended as a technical analysis and confluence tool. Signals should always be confirmed with your own market analysis and proper risk management. This script does not provide financial advice. Penunjuk
ATR Trend Rail🚦 ATR Trend Rail — a trend rail that knows when to shut up.
Most ATR / SuperTrend clones flip you into every chop-fest, then repaint the "perfect" entry after the candle closes. This one doesn't. It runs on a single idea: a trailing ATR band is only worth trading when the market regime agrees with it. 🎯
WHAT'S UNDER THE HOOD
📐 The rail — a trailing ATR band that latches trend state and rides price until volatility says the move is done. Adaptive, clean, no lag-heavy MA soup.
🧭 Regime filter (the whole point) — every flip is gated against a regime SMA. Leave it on your chart timeframe, or point it at an HTF for a top-down bias. Wrong side of regime? The signal never fires. This is the piece most trend tools skip entirely.
🚫 Non-repainting, for real — flips confirm on closed bars only, the regime pull runs lookahead-off with a realtime offset, and each leg's regime status locks the moment the flip bar closes. What you see in replay is what you'd have traded live. No hindsight magic.
🌫️ Faded legs — trends that fire against regime don't disappear, they dim. You still see the move; you just know it didn't earn a signal. Context, not censorship.
🔔 Alerts that behave — Bull, Bear, and Flip, confirmed-bar only. Set them once and trust them.
READ IT IN ONE GLANCE
🟢 Bright rail under price → confirmed uptrend, regime agrees
🔴 Bright rail over price → confirmed downtrend, regime agrees
⚪ Faded rail → the move exists, regime says wait
🔺 Triangle + Bull / Bear tag → a flip that passed the gate
Still useful after it's been on your chart a while. 🚦
— SlatinaTrades Penunjuk
Penunjuk
XRS Pro Auto Anchored VWAP + SFP Reversals Alerts + EMA/SMAXRS Pro Auto Anchored VWAP + SFP Reversals Alerts + EMA/SMA
Professional multi-session VWAP, institutional standard deviation bands, structurally validated Swing Failure Pattern (SFP) detection, intelligent alerts, and optional moving averages—all designed specifically for futures traders.
Unlike most VWAP indicators that only plot a line, this indicator combines multiple institutional reference points with automated reversal detection to help identify high-probability reaction areas and mean reversion opportunities.
Features
✔ Auto-Anchored VWAPs
Automatically plots four independent VWAPs:
• New York Session VWAP
• Asia Session VWAP
• Weekly VWAP
• Monthly VWAP
Each VWAP resets automatically at the appropriate session or calendar boundary.
For intraday traders this provides both short-term and higher-timeframe value references without manually changing anchors.
✔ True 1-Minute Anchoring
Includes an optional High Resolution Anchoring mode.
When enabled, every VWAP is calculated from actual 1-minute data regardless of the chart timeframe.
This allows:
• Accurate 9:30 NY resets
• Accurate 6:00 PM futures session resets
• Consistent values across all chart timeframes
• More precise deviation bands
If 1-minute history is unavailable, the indicator automatically falls back to the chart timeframe.
Institutional Standard Deviation Bands
The indicator plots the active session's:
• VWAP
• +1σ
• -1σ
• +2σ
• -2σ
These dynamically change based on whether the market is trading inside the New York or Asia session.
Different color schemes are used for each session so historical charts remain easy to interpret.
Band fills are fully customizable.
Automated Swing Failure Pattern (SFP) Detection
One of the primary features of this indicator is automatic SFP detection around institutional value areas.
The script identifies Swing Failure Patterns occurring at:
• Active Session VWAP
• ±1 Standard Deviation
• ±2 Standard Deviation
• Outside Band 2
Instead of simply detecting wick sweeps, every SFP is tracked through a structural lifecycle.
This dramatically reduces low-quality signals.
Structural Validation
Most SFP indicators print a marker immediately and never verify whether the reversal actually develops.
This indicator is different.
Every detected SFP is tracked after it forms.
Signals remain active until one of two things happens:
• The market confirms the reversal by breaking the opposite structure.
• The setup structurally fails and the signal is automatically removed.
This helps eliminate many false positives while leaving confirmed reversals visible on the chart.
Signal Modes
Choose how many reversal signals are displayed.
Available modes:
All Qualified SFPs
Displays:
• VWAP SFPs
• Band 1 SFPs
• Band 2 SFPs
• Outside Band 2 SFPs
• Band 2 Re-entry SFPs
VWAP Only
Displays only SFPs occurring near the active session VWAP.
Ideal for traders who primarily trade mean reversion.
Outside Band 2 Only
Displays only extreme exhaustion reversals beyond ±2 standard deviations.
Perfect for traders looking for stretched markets.
Outside Band 2 Logic
Unlike ordinary proximity-based signals, every structurally valid Swing Failure Pattern occurring beyond Band 2 is detected regardless of its distance from the band.
This allows significant exhaustion reversals to be captured even when volatility temporarily extends beyond the standard deviation envelope.
Intelligent Marker System
Signals use compact premium-style markers:
B = Bullish Reversal
S = Bearish Reversal
Markers remain clean and unobtrusive while still being easy to identify.
Built-in moving averages include:
• EMA 9
• EMA 21
• EMA 50
• EMA 100
• SMA 50
• SMA 200
Each average has independent:
• Color
• Width
• Visibility
This allows the indicator to replace several separate moving-average indicators.
Alerts
Built-in alerts include:
Current Market Alerts
• Current Session VWAP Touch
• Upper Band 2 Break
• Lower Band 2 Break
• Any Band 2 Break
Swing Failure Pattern Alerts
• Bullish VWAP/Band SFP
• Bearish VWAP/Band SFP
• Any VWAP/Band SFP
• Bullish Band 2 Re-entry
• Bearish Band 2 Re-entry
• Bullish Outside Band 2
• Bearish Outside Band 2
• Any Active VWAP SFP
• Any Active Band 1 SFP
• Any Active Band 2 SFP
• Any SFP Signal Marker
• Any SFP at Active VWAP
• Any SFP Outside Band 2
• Bullish Confirmed SFP
• Bearish Confirmed SFP
Designed For
This indicator is especially useful for traders who utilize:
• VWAP Mean Reversion
• Auction Market Theory
• Volume Profile
• ICT Concepts
• Liquidity Sweeps
• Swing Failure Patterns
• Order Blocks
• Institutional Trading
• Futures Markets
While designed primarily around CME futures such as ES, NQ, MNQ, MES, CL, GC, RTY, and YM, it can also be used on equities, ETFs, forex, and cryptocurrencies.
Recommended Workflow
A common workflow is:
Determine the active session value using VWAP.
Identify whether price is trading near VWAP, ±1σ, or ±2σ.
Wait for a structurally valid Swing Failure Pattern.
Use the indicator's confirmation logic to filter weaker reversals.
Combine signals with your own market structure, volume profile, order flow, or risk management plan.
No indicator should be used in isolation. This tool is intended to enhance an existing trading plan by providing objective institutional reference levels and automated reversal detection. Penunjuk
Penunjuk
Penunjuk
Penunjuk
SMC Volume Boost Matrix v6◆ Overview
SMC Volume Boost Matrix v6 is an advanced TradingView indicator that combines Smart Money Concepts with volume analysis to help traders identify high-probability trading opportunities. By analyzing market structure together with volume momentum, the indicator highlights areas where institutional participation may be increasing, giving traders additional context for trend continuation and potential reversals.
The indicator is designed to simplify market analysis while providing clear visual information for decision-making across multiple financial markets.
◆ Features
• Smart Money Concepts (SMC) based market structure analysis
• Volume boost detection for stronger market confirmation
• Automatic Bullish and Bearish trend identification
• Clear BUY and SELL signal visualization
• Dynamic trend confirmation using price and volume
• High-volume breakout detection
• Early momentum shift recognition
• Professional on-chart visualization
• Real-time signal generation
• Customizable settings for different trading styles
• Suitable for Forex, Crypto, Stocks, Indices, and Commodities
• Compatible with scalping, intraday, and swing trading
◆ How It Works
SMC Volume Boost Matrix v6 monitors both price structure and trading volume simultaneously.
When market structure aligns with increasing volume, the indicator identifies stronger directional momentum. A bullish market structure supported by rising volume may indicate increasing buying pressure, while a bearish structure with strong volume may indicate increasing selling pressure.
Instead of relying on volume or price alone, the indicator combines multiple market factors to provide more informed trading signals.
◆ How To Use
Add SMC Volume Boost Matrix v6 to your TradingView chart.
Choose the timeframe that matches your trading strategy.
Wait for a confirmed BUY or SELL signal after market structure and volume conditions align.
Use the indicator together with key support and resistance levels, liquidity zones, or your existing trading plan for additional confirmation.
Apply proper risk management before entering any trade, including defining your stop-loss and profit targets. Penunjuk
Penunjuk
Prime Strategy SwingMarket Structure (BOS/CHoCH)
Automatically detects Break of Structure and Change of Character on a configurable higher timeframe, plotting labeled structure lines so you always know the current trend bias.
Swing Highs/Lows
Marks HH/LH/LL/HL swing points on a separate configurable timeframe, giving a clean read of higher-timeframe price action independent of your chart's timeframe.
Liquidity Pools
Tracks the last 5 unmitigated swing highs and lows as extending liquidity lines, automatically removing them once price sweeps through.
Order Blocks
Auto-detects bullish and bearish order blocks following a break of structure, with automatic mitigation (deletion) once price returns to tap them.
Premium/Discount Zones with Fibonacci Levels
Draws a dynamic zone from the latest swing structure with 15%/30%/50%/70%/85% fib levels, shading the "premium" (sell) and "discount" (buy) halves so you can visually gauge where price sits in the current range.
Nadaraya-Watson Envelope Filter
An optional smoothed regression filter (Gaussian-weighted) used to confirm entries are occurring at statistical extremes, not just at fib levels.
200 EMA (slope-colored)
A 200-period EMA (length adjustable) that changes color based on its own slope — teal when rising, red when falling — for an instant trend-bias read.
Auto Signals
Optional BUY/BUY PRIME and SELL/SELL PRIME labels that trigger when price taps the 70%/85% zones during a configurable session window (default NY session), with a daily signal cap to avoid overtrading. Alerts included.
Live Dashboard
Top-right panel showing current structure trend, last CHoCH direction, current zone status, and NW filter state at a glance.
Volume Profile (optional)
Builds a volume profile across the most recent swing range with POC (Point of Control) highlighted.
⚠️ This is a discretionary confluence tool, not a standalone signal system — always confirm with your own analysis and risk management. Penunjuk
ARDI Williams Vix FixThis indicator is a reconstructed, faster, and visually distinct version of the popular Williams Vix Fix indicator (originally created by Chris Moody and later expanded by theehoganator ).
What does this indicator do?
By measuring market volatility, this indicator identifies periods of extreme fear (panic selling) and extreme greed (euphoric buying) to help locate potential market reversal points.
🚀 Key Features & Upgrades in the ARDI Version
1. Faster Execution & Code Optimization
Fully rewritten based on Pine Script v6. All legacy, commented-out, and experimental code has been cleaned up to ensure smoother and more efficient script performance on your chart.
2. New Interface & Full Support for "Fear & Greed" Phases
The indicator's visuals have been completely redesigned to simultaneously display both tops (greed) and bottoms (fear) with clear visual signals.
Candle overlays on the main chart have been removed to keep your price chart clean for price action analysis.
3. New ARDI Filter
Market noise, weak candles, and erratic signals are filtered out, significantly reducing false entries during sideways (ranging) markets.
4. Clean & Organized Settings Menu
Parameters are logically grouped and organized to make adjusting settings straightforward.
5. Rewritten Alert System
Alert logic has been completely rewritten and optimized for fast signal triggering, making it ideal for webhooks, trading bots, or mobile notifications.
💡 Important Note on Settings
The default settings have been specifically optimized for this version. However, if you adjust the input values to match the reference indicator settings, you will receive the exact classic signals.
Disclaimer: Past performance is not indicative of future results. Always practice proper risk management. Penunjuk
Weis Wave with Main Pane Renko Volume LabelsWeis Wave with Renko Peak/Trough Volume Labels
This script is an amended/forked version of the original “Weis Wave Volume” indicator published by modhelius.
Full credit is given to modhelius for the original Weis Wave Volume calculation, Renko assignment methodology and histogram implementation. The original calculation has been retained, converted to Pine Script v6 and extended with automatic price-chart labels and connector lines.
OVERVIEW
The indicator accumulates volume, or True Range where selected, into directional Weis Waves. The completed wave values are displayed as columns in the lower indicator pane.
This amended version additionally places each completed Weis Wave value on the main Renko price chart at the corresponding wave peak or trough.
Up-wave values are displayed using green labels and down-wave values using red labels by default.
PEAK AND TROUGH LABELS
When a directional wave is completed:
• The script identifies the Renko box containing the actual peak or trough of that wave.
• The completed Weis Wave volume value is placed above or below that box, according to the user settings.
• A vertical connector line links the centre of the relevant Renko box to its value label.
• The label is positioned retrospectively at the completed wave extreme once the subsequent change of direction confirms the wave.
The labels therefore identify the completed wave rather than the first brick of the new opposing wave.
CURRENT UNCOMPLETED WAVE
An optional provisional label displays the accumulated value of the current uncompleted wave.
The provisional label:
• Moves when the current wave makes a new peak or trough.
• Updates as additional volume is accumulated.
• Uses a translucent label and dashed connector line to distinguish it from confirmed wave values.
• Remains subject to change until an opposing wave confirms completion.
The provisional label can be disabled independently.
USER SETTINGS
The script provides controls for:
• Renko assignment method: ATR, Traditional or Part of Price.
• Renko assignment value.
• Price source.
• Use of volume or True Range.
• Oscillating histogram display.
• Normalised wave values.
• Completed-wave labels on or off.
• Current uncompleted-wave label on or off.
• Peak-label placement above or below the peak.
• Trough-label placement above or below the trough.
• Independent peak and trough vertical distances.
• Distance measured in Renko boxes, minimum ticks or price units.
• Label font size.
• Connector lines on or off.
• Connector-line thickness.
• Volume-value divisor.
• Number of decimal places.
• Maximum number of historical labels retained.
TIMEFRAME
The indicator calculates using the current chart timeframe. It does not use a separate indicator timeframe because the Weis Wave calculation, Renko structure and price-chart labels must remain aligned.
RENKO CHART NOTE
Renko charts are synthetic charts constructed from price movement rather than fixed time intervals. Wave boundaries and accumulated volume values may therefore change when the chart timeframe, Renko method or Renko box size is changed.
For consistent comparisons, use the same Renko configuration and indicator settings.
This indicator is intended as an analytical visualisation tool. It does not generate trading entries, exits or investment recommendations.
CREDIT
Original Weis Wave Volume script and core calculation:
modhelius
Pine Script v6 conversion and extensions:
Automatic Renko peak/trough labels, adjustable positioning, connector lines and provisional current-wave display. Penunjuk
Liquidity Sweep Hunter | AlphaScript💧 Liquidity Sweep Hunter
Liquidity Sweep Hunter maps the resting liquidity at swing highs and lows — the stop orders sitting just beyond obvious pivots — and detects when price raids it. It marks each level as resting, swept, or reclaimed, so you can see both where liquidity is waiting and when it gets taken.
💡 The idea behind it
Stop orders cluster just beyond swing highs and swing lows. Above a swing high sit the stops of short sellers and the buy orders of breakout traders — buy-side liquidity (BSL). Below a swing low sit the opposite — sell-side liquidity (SSL). Larger participants are drawn to these pools because that resting liquidity is what fills their orders. When price spikes through a level, takes the stops, and rejects back, that is a liquidity sweep — often the origin of a reversal. This tool identifies those events systematically instead of by eye.
🔍 How detection works
Levels are anchored to confirmed swing pivots (default lookback 10 bars each side). A swing high becomes a buy-side liquidity level; a swing low becomes a sell-side liquidity level. Pivots are only registered after they are fully confirmed, so levels do not repaint. Each level is drawn as a line and tagged so its state is always clear:
⇠ Resting — an unswept level. The stops are still sitting there; price may return to raid it. Tagged BSL ⇠ (above swing highs) or SSL ⇠ (below swing lows). These are potential targets.
✗ Swept — price wicked through the level but the bar closed back on the original side. The stops were taken and price rejected. Tagged ✗ BSL swept or ✗ SSL swept.
⟲ Reclaimed — price closed through the level, then on a later bar closed back across it: a failed break that reclaimed the level. Tagged ⟲ BSL reclaimed or ⟲ SSL reclaimed.
You choose the detection mode: Wick (sweeps only), Reclaim (break-and-reclaim only), or Both.
🎯 Penetration filter
An optional ATR-based filter requires price to pierce the level by a minimum multiple of ATR before an event qualifies. Because it is measured in ATR rather than fixed ticks, it means the same thing across every instrument — no re-tuning when you switch markets. Set to zero to disable.
🟠 Broken levels
In Reclaim and Both modes, a level that price closes through is kept on the chart in a distinct color and tagged while it awaits a possible reclaim — so you can see levels that failed but might still be reclaimed. These can be toggled off for a cleaner chart.
📊 Dashboard
A compact panel shows the current symbol, the number of active buy-side and sell-side levels being tracked, and the active detection mode. Theme (dark/light), size, and position are all configurable.
🎨 Customization
Full control over the look: colors for bullish/bearish events, level lines, and broken levels; line style and width for both level lines and event lines; label text color (for readability on light or dark charts); how far pending level lines extend; and toggles for level lines, event labels, pending-level tags, and broken levels.
📈 How to use it
Watch the resting (⇠) levels as the liquidity price may be drawn toward. When a swing high is swept (✗ BSL) after an up-move, buy-side liquidity has been taken and a move down may follow; a swept swing low (✗ SSL) can signal the reverse.
Reclaim events flag failed breaks that often precede a move back in the reclaim direction. Use the tags as points of interest to combine with your own structure read, higher-timeframe bias, and risk management — the tool shows where liquidity rests and when it is taken; you decide what to do with it.
🔔 Alerts
Separate alerts for SSL sweep, BSL sweep, SSL reclaim, BSL reclaim, plus combined "Any Sweep" and "Any Reclaim" conditions.
⚙️ Settings
Swing lookback, detection mode, ATR penetration filter, maximum active levels, level age limit, visible-event cap, recent-bars window for signal shapes, plus the full display and customization controls above.
📌 Notes
This tool detects liquidity at swing pivots specifically — individual swing highs and lows. It is one lens on liquidity and pairs naturally with equal-high/low and session-level analysis for a fuller picture. Events are confirmed on closed bars and do not repaint intrabar. A liquidity sweep marks where stops were taken, not a guaranteed reversal — always combine with your own analysis and risk management. Penunjuk
Penunjuk
